Code: Ea00010 | Details: COMPONENT DATA ERROR: Failed to download the component data. Memory for component data is full. Code: Ea00011 | Details: COMPONENT DATA ERROR: This component data already exists. Code: Ea00012 | Details: COMPONENT DATA ERROR: The component shape is illegal. Code: Ea00013 | Details: VISION BUSY ERROR: Vision system is now recognizing. […]
Category Archives: SMT Machines MRO
02
Sep
Sep
Code 1: Ea00000 | Details: NO ERROR MESSAGE REGISTRATION, Error message for this error is not registered. Please consult your distributor for further information with this error number. Code 2: Ea00001 | Details: CORRECTION DATA ERROR: Only 1 Lead is detected. Code 3: Ea00002 | Details: CORRECTION DATA ERROR: Corrected data is not loaded. Or […]
01
Sep
Sep
4.2.1 Consumables, Spare and Wear Parts, Tools Lint-free cloths [03082092-xx] SIPLACE cleansing tissue [00315253-xx] Protective latex gloves [00372972-xx] Rust prevention spray WD40, 400 ml [00325833-xx] Sheet of DIN A4 paper ESD wristband [00320279-xx] Vacuum cleaner with appropriate nozzle New compressed air filter, if required: – Filter element 5 μm [03050213-xx] HSxx / D1 / D2 […]
31
Aug
Aug
CAUTION Filter elements The maintenance intervals given for inspecting and replacing the filter elements only apply to the specified compressed air quality (see user manual). If other qualities are used, the maintenance intervals should be shortened accordingly.
28
Aug
Aug
For maintenance work performed on the TwinHead, CPP and C&P20(A) heads we recommend using the “Starter kit for CPx and TwinHead maintenance” [03071171-03]. We also recommend using additional multipettes [03078989-xx], so that the combitips do not need to be changed when lubricating multiple heads. Consumables: Wear Parts and Spare Parts: Tools:
27
Aug
Aug
The reference plane for Z-axis height of the tape feeder is beneath (above the main frame) the tape at the pickup position. Actual pickup height of each part may vary depending on part height and transfer tape thickness as shown in the following figure. In particular, embossed tape must be set according to the actual […]
26
Aug
Aug
Tape to be used/reel diameter/feed pitch/number of occupied slots according to feeder types Table1.1 Types of feeder, width of the tape, and feed pitch Type of Feeder [1] Width of the tape(mm) Feed Pitch (mm) Reel Diameter (mm) Number of occupied Slots SME 8mm Tape Feeder 8 2, 4 ф178~180 1 SME 8mm Tape Feeder […]
25
Aug
Aug
Note: 3 Consumables, Spare and Wear Parts, Tools: The following lists contain all necessary consumable materials, wear and spare parts plus tools for performing maintenance tasks to the machine and placement heads. For maintenance work to the SIPLACE X series we recommend using the “Service box for X and SX series [03079042-xx]”. Consumables: #1. OIL […]
24
Aug
Aug
Figure 1.1 Configuration of SME 8mm tape feeder #1 Part Name: Tape Guide #2 Part Name: Locker #3 Part Name: X Eccentric Pin #4 Part Name: Location Flange #5 Part Name: Installation Guide #6 Part Name: Clamping Roller #7 Part Name: Probe Pin #8 Part Name: Reel Plate #9 Part Name: Vinyl Cutter #10 Part […]
21
Aug
Aug
Step 1: Installing calibration jig Connect the power cable to the receptacle. Supply pneumatic air to the jig. Turn on the switch attached on the rear side of the jig. Press the power switch attached on the monitor to turn on the monitor. Step 2: Checking the calibration jig and master jig Check the offset […]
