Table 1-5. The pick & place Cycle Time for Each Model Classification 1: Chip CP-45FV: 0.197sec / component(1608) Classification 2: QFP CP-45FV: 0.75 sec / component (Flying Vision) and 1.6 sec / component (Stage Vision) Classification 3: Connector CP-45FV: 0.5 sec / component (Flying Vision) and 1.6 sec / component (Stage Vision) Remarks: Simultaneous pickups […]
Category Archives: SMT Machines MRO
30
Jul
Jul
Figure 1-2. The Summary for Measuring the Tact Time (6 Heads Simultaneous Pickups, Each heads place) 1.2.4. The Pick & Place Cycle Time The descriptions given below refer to the best performance that can be obtained from the pick & place cycle time. The actual cycle time can vary depending on the size of PCB, […]
29
Jul
Jul
The placement precision for applicable components type is shown in Table 1-4, and is applicable to general components usage as well. Table 1-4. The placement Precision Classification: Chip 0603 Placement precision: ± 0.08 | Remarks: FOV15mmFlying vision (CP-45FS) Classification: Chip 1005 Placement precision: ± 0.1 | Remarks: FOV15mm Flying vision (CP-45FS) Classification: QFP Placement precision: […]
28
Jul
Jul
Table 1-3. Applicable Component Sizes (Vision Recognition System) 1. Classification: IC , Connector. (1)Standard FOV35mm 17mm: 0.3 mm pitch 32mm: 0.4 mm pitch 40mm: 0.5 mm pitch (MFOV for more than 32mm) (2)Option FOV20mm Chips 1005: 17mm: 0.3 mm pitch (3)Option FOV45mm 32mm: 0.4 mm pitch 42mm: 0.5 mm pitch 2. Classification: BGA. (1)Standard FOV35mm […]
27
Jul
Jul
This is used to just create an relationship between the part and the feeder in which the part is set. An ID can be created between a part and a feeder at any time. When an ID is created, this simply creates a relationship and performs no other checks such as if the part is […]
24
Jul
Jul
The sizes of components applicable to this equipment are prescribed in Table 1-2, and is applicable to general components usage as well. Table 1-2. Applicable Component Sizes (vision recognition system) 1. Classification for CP-45FV Standard (FOV 25mm Lens): Chips: 1005 IC, Connector: 22.0mm , Lead Pitch : 0.5mm BGA,CSP: 17.0mm, Ball Pitch : 0.75mm 2. […]
23
Jul
Jul
1.2.1. Configuration of the head and vision recognition system The vision recognition systems of the CP-45F/V and CP-45FS related to the components placed are as shown in Table 1-1 Table 1-1. Configuration of the Head and Vision Recognition System (1) Classification: CP-45FV | Head Structure Head 1/2/3/4/5/6: 25mm Vision | Vision System: -35mm Vision (2) […]
22
Jul
Jul
It is essential to create IDs or to perform a quick verify before setting parts on a machine. Creating IDs and performing a quick verify create relationships between reels and feeders. Before performing this, the parts DID and feeder barcodes must already be registered in the Fujitrax Verifier database or an error will occur while […]
21
Jul
Jul
The machine models are CP45F NEO, CP45FV NEO, CP45FSNEO, CP45FSV NEO, CP45F-L NEO, CP45FV-L NEO, CP45FSL NEO and CP45FSV-L NEO, and CP45F-L NEO, CP45FV-L NEO, CP45FS-L NEO and CP45FSV-L NEO are large-sized PCB models.(The Large PCB Model). Teach Refers to a process that transmits the coordinate of a point on the machine using a teaching […]
20
Jul
Jul
Chapter 1. Features and Scope of Equipment “Overview“ includes features, specifications, names, functions, auxiliary equipment, installation, and production preparation procedures of the CP Series. Full understanding of “Overview“ prior to the operation of this equipment is required. 1.1 Features of Equipment The CP series CP-45F/V and CP-45FS of Samsung Techwin Co.,Ltd. are multi-purpose, high-precision component […]
