1.3.1. Size And Weight Of The Equipment
Length
Including Cover: 1,660mm
Excluding projection of Conveyor Unit: 1,502mm
Width: 1,540mm
Height
Up to the upper surface of cover: 1,408mm
Up to the upper surface of monitor: 1,760mm
Up to the upper surface of tower lamp: 1,945mm
Weight: 1,150 kg
1.3.2. Requirements For Air Pressure
Pressure: 4.5 ~ 5.5 kgf/cm2
Air Consumption: 150 N l /min
Dry Air: air dew point of -17°C or less
1.3.3. Environmental Conditions
During operation
Temperature: +10°C ~ +35°C
Humidity
Less than 50% RH (35°C)
Less than 90% RH (20°C)
During shipment or storage (in states other than during operation)
Temperature: -10°C ~ +60°C
Humidity: 20% RH ~ 90% RH (non-condensation state)
1.3.4. Noise
The CP-45F/V and the CP-45FS machine has a noise level not exceeding 80 dB with the front and rear covers closed. The noise is measured at the upper surfaces of the front and rear feeder bases while operating the equipment at 100% speed and driving all x-axis, y-axis, and z-axis to the maximum stroke.
