#A P/N: AM03-008135B | Assy,Optics V1P Stage Camera Assy | Qty: 4
#B P/N: AM03-008825A | Assy,Optics V1P Stage Side Light Assy | Qty: 1
#C P/N: AM03-008135B | Assy,Optics V1P Stage Camera Assy | Qty: 1 | Old part number: Am03-000870A / Am03-008135A
#1 P/N: J71801207A | Spacer Plate | Qty: 2
#2 P/N: J70811085A | Light Base | Qty: 1
#3 P/N: J67541028A | Cover Glass | Qty: 1
#4 P/N: J73591002A | Tape S | Qty: 1
#5 P/N: J73591001A | Tape L | Qty: 2
#6 P/N: J70811088A | Cover | Qty: 1
#7 P/N: J70811089A | Holder Main | Qty: 1
#8 P/N: FC18-903190 | Tie Mount | Qty: 4
#9 P/N: J67551020A | Beam Splitter N | Qty: 1
#10 P/N: J71801205A | Mirror Stand | Qty: 2
#11 P/N: J70811092A | Mirror Holder | Qty: 2
#12 P/N: FC39-001658A | Diffuser | Qty: 1 | Old part number: J72801052A
#13 P/N: J71801206A | Cled Base | Qty: 1
#14 P/N: FC18-901194 | Dowel Pin[Ms4-10] | Qty: 4
#15 P/N: AM06-002282A | Asssy,Pcb Smd-Coaxial Pcb (B-Type) | Qty: 1
#16 P/N: J70811084A | Shutter Plate | Qty: 1
#17 P/N: FC29-900604 | Hex Support [M3*15(Bolt-Nut)] | Qty: 4
#18 P/N: J70811090A | Base Plate | Qty: 1
#19 P/N: J70811086A | S Washer | Qty: 3
#20 P/N: J70811087A | Holder Sub | Qty: 1
#21 P/N: J70811095A | Pole | Qty: 2
#22 P/N: FC39-001657A | Diffuser Transparent PC | Qty: 1
#23 P/N: EP07-000259A | Insulator Insulator | Qty: 1
