Sub Stage Camera A AM03-008825A
#A P/N: AM03-008825A | Assy Optics-V1P Stage Side Light Assy | Qty: 1
#1 P/N: FC30-001629A | Plate-Top Cover Fid | Qty:1 | Old part number: J70811075A
#2 P/N: J72801053A | P Cover | Qty: 1
#3 P/N: EP16-002102A | Pcb Led-Excen Pro Side Ill Pcb B 12 Ep16-000040A
#4 P/N: EP16-002103A | Pcb Led-Excen Pro Side Ill Pcb A 12 Ep16-000039A
#5 P/N: J70811081A | Up Base Holder | Qty: 1
#6 P/N: J70811077A | Side Coverlb | Qty: 1
#7 P/N: FC09-002111A | Bracket Mounting-V1P091-Side Lighting Ba | Qty: 1
#8 P/N: J70811078A | Side Coverlb | Qty: 1
#9 P/N: J70811079A | Side-Covers | Qty: 2
#10 P/N: J70811082A | Mid Base Holder | Qty: 1
#11 P/N: J70811083A | Low Base Holder | Qty: 1
#12 P/N: FC30-002034A | Plate-Mtv1Pp-Op105A-Top Cover Fid
Sub Stage Camera B AM03-000870A
#B P/N: AM03-000870A | Lens Camera Assy | Qty: 1
#1 P/N: AM03-000868A | Assy Optics-V1 Stage Lens Ass’y | Qty: 1
#2 P/N: J71801208A | Front Barrel | Qty: 1
#3 P/N: J71801101A | Rear Barrel | Qty: 1
#4 P/N: J71801209A | Adjust Holder | Qty: 1
#5 P/N: J71801210A | Adjust Plate | Qty: 1
#6 P/N: PT02-001006 | Camera-Sc-D500X;2/3″ | Qty:1 | Old part number: Pt02-900014
#7 P/N: J71801212A | Adjust Plate | Qty: 1
#8 P/N: J71591053A | Cam Screw T | Old part number: J71591053A
