#1. P/N: AM03-014220A | Part name: Cable Assy Hph V1+ Z Motor Cable (30W) | Qty: 2
#2. P/N: MC22-000076 | Part name: Coupling Sakai Ra16C 5X5 | Qty: 2
#3. P/N: FC29-001029A | Part name: Holder Holder Motor A5056 H34 | Qty: 2
#4. P/N: FC29-001014A | Part name: Holder Holder Motor Z A5052 H34 | Qty: 2
#5. P/N: FC09-002005A | Part name: Bracket Motor Motor A2024 T4 | Qty: 1
#6. P/N: FC18-000998 | Part name: Spacer Spacer Cl 310E Cl 312E | Qty: 2
#7. P/N: FC18-000933 | Part name: Washer Flat Wssm8 6 2 | Qty: 2
#8. P/N: FC18-000936 | Part name: Nut Bearing Lock Nut | Qty: 2
#9. P/N: MC03-900091 | Part name: Angular Bearing Ac6 16Dfsp2 | Qty: 2
#10. P/N: FC29-001013A | Part name: Support Support Bearing A5052 H34 | Qty: 2
#11. P/N: FC18-000955A | Part name: Spacer Spacer 4 8 3 | Qty: 2
#12. P/N: MC13-000145 | Part name: Screw Ball | Qty: 2
#13. P/N: HP06-000219 | Part name: Fitting Nipple Elbow Miniature | Qty: 2
#14. P/N: MC13-000235 | Part name: Lm Guide Mlc12C2R150T1Hs1 150 25 2 H T1 | Qty: 2
#15. P/N: FC07-000484B | Part name: Block Holder Blk | Qty: 2
#16. P/N: FC30-001021B | Part name: Plate Under Spcc | Qty: 1 | Old P/N: FC30-001021A
#17. P/N: FC30-001020B | Part name: Plate Base Plate | Qty: 1 | Old P/N: FC30-001020A
#18. P/N: FC18-001180 | Part name: Washer Flat Wsss10 5 2 Sus304 D10 D5 2 | Qty: 1
#19. P/N: FC07-000483A | Part name: Block Manihold A2024 T4 | Qty: 1
#20. P/N: HP14-000960 | Part name: Valve Solenoid Vqz115R 5Moz1 Cp X550 Q | Qty: 2
#21. P/N: HP14-000961 | Part name: Valve Solenoid Vqz115R 5Moz1 Cp X559 Q | Qty: 2
#22. P/N: HP06-900224 | Part name: Straight Fitting Hp06 900224 | Qty: 1
#23. P/N: HP06-900016 | Part name: Fitting [Kq2S04 M5/Poc4 M5M] | Qty: 4
#24. P/N: EP19-000185 | Part name: Sensor Presser Sensor Pse541 M5 | Qty: 2
#25. P/N: FC18-902722 | Part name: Socket Head Cap Screw M3*8 (Ni/Zn) 1 | Qty: 2
#26. P/N: FC18-902743 | Part name: Socket Head Cap Screw M4*12 (Ni/Zn) | Qty: 1
#27. P/N: FC18-90321938 | Part name: Flat Washer [M4 (Bl/Zn)] | Qty: 1
#28. P/N: FC18-902749 | Part name: Socket Head Cap Screw M4*25 (Ni/Zn) | Qty: 1
#29. P/N: FC18-902728 | Part name: Socket Head Cap Screw M3*12 (Ni/Zn) | Qty: 1
#30. P/N: FC18-000127 | Part name: Pin Stage Dowel Pin Ms3 8 Me1 Steel | Qty: 1
#31. P/N: FC18-000538A | Part name: Screw Etc Gutb5 Hex Hex M5 19 Steel | Qty: 1
