What is Panasonic Panasert AJ Series Auto-Insert Replacement Parts Through Hole Thru-hole Inserter Spare Part. Axial Inserter Part 0422196 PIN – 0432122 PUSHER?
Looking for Panasonic Panasert AJ Series Auto-Insert Replacement Parts Through Hole Thru-hole Inserter Spare Part. Axial Inserter Part 0422196 PIN – 0432122 PUSHER? This SMT spare part (SKU: AUTO-INSERT, Brand: Panasonic) is a high-precision component for SMT pick-and-place machines. Contact SMTBOX for competitive bulk prices, global delivery options, and fast RFQ turnaround.
Panasonic Panasert AJ Series Auto-Insert Replacement Parts Through Hole Thru-hole Inserter Spare Part. Axial Inserter Part.
| No. | Part No. | Part Name |
|---|---|---|
| 201 | 0422196 | PIN |
| 202 | 0424001 | SPROCKET |
| 203 | 0424015 | |
| 204 | 0424020 | HOUSING |
| 205 | 0424025 | HOUSING |
| 206 | 0424037 | SPROCKET WHEEL |
| 207 | 0430022 | BALL PUSHER |
| 208 | 0430023 | WIRE GUIDE |
| 209 | 0430024 | SPRING (6313046.6313011) |
| 210 | 0430025 | GUIDE |
| 211 | 0430026 | 0564032 WIRE GUIDE |
| 212 | 0430027 | BLOCK |
| 213 | 0430036 | BLOCK |
| 214 | 0430041 | GUIDE |
| 215 | 0430042 | HOLDING PLATE |
| 216 | 0430046 | ROLLER |
| 217 | 0431001 | ROLLER |
| 218 | 0431002 | PIN |
| 219 | 0431003 | LEVER |
| 220 | 0431011 | SHAFT |
| 221 | 0431013 | RATCHET LEVER |
| 222 | 0431016 | SPRING |
| 223 | 0431017 | SPRING |
| 224 | 0431019 | TAPE GUIDE |
| 225 | 0431020 | PIN |
| 226 | 0431022 | TAPE GUIDE |
| 227 | 0431101 | TAPE GUIDE |
| 228 | 0431105 | TAPE WHEEL(L) |
| 229 | 0431106 | TAPE WHEEL(R) |
| 230 | 0431110 | |
| 231 | 0431201 | TAPE GUIDE |
| 232 | 0432000 | CUTTER FRAME |
| 233 | 0432001 | CYINDER COVE |
| 234 | 0432002 | SPRING |
| 235 | 0432003 | PISTON |
| 236 | 0432004 | SPRING |
| 237 | 0432005 | SPRING |
| 238 | 0432006 | ROLLER |
| 239 | 0432007 | |
| 240 | 0432008 | LEVER |
| 241 | 0432009 | CUTTER |
| 242 | 0432012 | CUTTET |
| 243 | 0432014 | CUTTER |
| 244 | 04321001 | CUTTER UNIT |
| 245 | 04321002 | |
| 246 | 0432101 | LEVER |
| 247 | 0432102 | PUSHER |
| 248 | 0432103 | INSERTION GUIDE |
| 249 | 0432106 | SPRING |
| 250 | 0432122 | PUSHER |
The Panasonic Panasert AJ Series Auto-Insert Replacement Parts Through Hole Thru-hole Inserter Spare Part. Axial Inserter Part 0422196 PIN – 0432122 PUSHER (SKU: AUTO-INSERT) is a premium-grade SMT spare component manufactured for high-speed pick and place machines. Designed for maximum durability and precision, this part is part of our extensive AI Spare Parts for Panasert Thru-hole, Panasonic SMT Spare Parts, Thru-hole Parts, PANASONIC Thru-hole AI Spare Parts, Through-hole Machines Spare Parts inventory. It ensures seamless integration and high efficiency on active PCB assembly lines.
How to use Panasonic Panasert AJ Series Auto-Insert Replacement Parts Through Hole Thru-hole Inserter Spare Part. Axial Inserter Part 0422196 PIN – 0432122 PUSHER?
For optimal performance and durability, this component should be installed and calibrated by a certified SMT maintenance engineer. Regularly check the alignment, wear patterns, and vacuum suction parameters (for nozzles) to prevent component mispicks and ensure high assembly yields.
- Power down your mounter and disconnect the vacuum line.
- Clean the nozzle shaft or feeder mounting slot with ESD-safe cleaning alcohol.
- Carefully align the new component and tighten to the manufacturer's torque specifications.
- Perform a test cycle and verify the component alignment using mounter diagnostics before resuming full production.
