What is Panasonic KME Panasert CM401 CM402 CM602 CM212 DT401 DT400 SMD Nozzle for Multi-functional head?
Looking for Panasonic KME Panasert CM401 CM402 CM602 CM212 DT401 DT400 SMD Nozzle for Multi-functional head? This SMT spare part (SKU: head-dup-193, Brand: Panasonic) is a high-precision component for SMT pick-and-place machines. Contact SMTBOX for competitive bulk prices, global delivery options, and fast RFQ turnaround.
Nozzle for Multi-functional head CM401-M CM401-L CM402-M CM402-L CM400-M CM602-L CM212-M DT401-M DT401-F DT400-M MODULE NUMBER Nozzle
| NO | PART NUMBER | PART NAME | TYPE | Q’TY | RANK | REMARKS |
|---|---|---|---|---|---|---|
| 1 | KXFX037SA00 | NOZZLE No.1001 | N/A | 1 | N/A | N/A |
| 2 | KXFX037TA00 | NOZZLE No.1002 | N/A | 1 | N/A | N/A |
| 3 | KXFX037UA00 | NOZZLE No.1003 | N/A | 1 | N/A | N/A |
| 4 | KXFX037VA00 | NOZZLE No.1004 | N/A | 1 | N/A | N/A |
| 5 | KXFX037WA00 | NOZZLE No.1005 | N/A | 1 | N/A | N/A |
| 6 | KXFX037XA00 | NOZZLE No.1006 | N/A | N/A | N/A | N/A |
| 7 | KXFB01MHA00 | NOZZLE | N/A | N/A | N/A | N/A |
| 8 | KXFX03DXA00 | NOZZLE | N/A | N/A | N/A | N/A |
| 9 | KXFX03DZA00 | NOZZLE | N/A | N/A | N/A | N/A |
| 10 | KXF07QUAA00 | PAD | KP-8-N | N/A | N/A | N/A |
| 11 | KXF07QVAA00 | PAD | KP-10-N | N/A | N/A | N/A |
| 12 | KXFX03DRA00 | REFLECTOR | N/A | N/A | N/A | N/A |
| 13 | KXFB03KNA00 | BOLT | N/A | N/A | N/A | N/A |
| 14 | KXFX03DTA00 | NOZZLE | N/A | N/A | N/A | N/A |
| 15 | KXFB03KPA00 | SCREW | N/A | N/A | N/A | N/A |
| 16 | KXFX03DVA00 | NOZZLE | N/A | N/A | N/A | N/A |
The Panasonic KME Panasert CM401 CM402 CM602 CM212 DT401 DT400 SMD Nozzle for Multi-functional head (SKU: head-dup-193) is a premium-grade SMT spare component manufactured for high-speed pick and place machines. Designed for maximum durability and precision, this part is part of our extensive Panasonic SMT Nozzle, Panasonic SMT Spare Parts, Thru-hole Parts inventory. It ensures seamless integration and high efficiency on active PCB assembly lines.
How to use Panasonic KME Panasert CM401 CM402 CM602 CM212 DT401 DT400 SMD Nozzle for Multi-functional head?
For optimal performance and durability, this component should be installed and calibrated by a certified SMT maintenance engineer. Regularly check the alignment, wear patterns, and vacuum suction parameters (for nozzles) to prevent component mispicks and ensure high assembly yields.
- Power down your mounter and disconnect the vacuum line.
- Clean the nozzle shaft or feeder mounting slot with ESD-safe cleaning alcohol.
- Carefully align the new component and tighten to the manufacturer's torque specifications.
- Perform a test cycle and verify the component alignment using mounter diagnostics before resuming full production.
