What is Panasonic KME Panasert CM120-MU CM20F-M CM201 CM202 CM301 M9 Type Tape Feeder M9B5CSM0000 8mmx2mm W80.5P Large Reel?
Direct Answer / Quick Facts:
Looking for Panasonic KME Panasert CM120-MU CM20F-M CM201 CM202 CM301 M9 Type Tape Feeder M9B5CSM0000 8mmx2mm W80.5P Large Reel? This SMT spare part (SKU: M9B5CSM0000., Brand: Panasonic) is a high-precision component for SMT pick-and-place machines. Contact SMTBOX for competitive bulk prices, global delivery options, and fast RFQ turnaround.
We offer Panasonic KME Panasert CM120-MU CM20F-M CM201 CM202 CM301 M9 Type Tape Feeder M9B5CSM0000 8mmx2mm W80.5P Large Reel. Pls reach sales@smtbox.com
Panasonic/KME/Panasert CM120-MU CM20F-M CM201 CM202 CM301 M9 Type Single Tape Feeder
| No. | Part No. | Unit Name / Part Name |
|---|---|---|
| 1 | M9A1CSM0000 | 8mm x 4mm Tape Feeder. Emboss.W8*1P.Wide. Small Reel |
| 2 | M9A1CVM0000 | 8mm x 4mm Tape Feeder. Emboss. W8*1P.Wide. Large Reel |
| 3 | M9A1NSM0000 | 8mm x 4mm Tape Feeder. Emboss. W8*1P.Small Reel |
| 4 | M9A1NVM0000 | 8mm x 4mm Tape Feeder. Emboss. W8*1P.Large Reel |
| 5 | M9A5NSM0000 | 8mm x 2mm Tape Feeder. Emboss. W8*0.5P.Small Reel |
| 6 | M9A5NVM0000 | 8mm x 2mm Tape Feeder. Emboss. W8*0.5P.Large Reel |
| 7 | M9B1CSM0000 | 8mm x 4mm Tape Feeder. Paper. W8*1P. Small Reel |
| 8 | M9B1CVM0000 | 8mm x 4mm Tape Feeder. Paper. W8*1P. Large Reel |
| 9 | M9B5CSM0000 | 8mm x 2mm Tape Feeder. Paper. W8*0.5P.Small Reel |
| 10 | M9B5CVM0000 | 8mm x 2mm Tape Feeder. Paper. W8*0.5P.Large Reel |
| 11 | M9C1CSM0000 | 12mm x 4mm Tape Feeder. Emboss. W12*1P.Small Reel |
| 12 | M9C1CVM0000 | 12mm x 4mm Tape Feeder. Emboss. W12*1P.Large Reel |
| 13 | M9C1NSM0000 | 12mm x 4mm Tape feeder. plastic W12*1P.small reel |
| 14 | M9C1NVM0000 | 12mm x 4mm Tape feeder. plastic W12*1P.eglar reel |
| 15 | M9C2CSM0000 | 12mm x 8mm Tape Feeder. Emboss. W12*2P.Small Reel |
| 16 | M9C2CVM0000 | 12mm x 8mm Tape Feeder. Emboss. W12*2P.Large Reel |
| 17 | M9C2NSM0000 | 12mm x 8mm Tape feeder. plastic W12*2P. small reel |
| 18 | M9C2NVM0000 | 12mm x 8mm Tape feeder. plastic W12*2P. eglar reel |
| 19 | M9C3CVM0000 | 12mm x 12mm Tape Feeder. Emboss. W12*3P.Large Reel |
| 20 | M9C3NVM0000 | 12mm x 12mm Tape feeder. plastic W12*3P. eglar reel |
| 21 | M9D1CVM0000 | 16mm x 4mm Tape Feeder. Emboss. W16*1P.Large Reel |
| 22 | M9D1DVM0000 | 16mm x 4mm Tape Feeder. Emboss. W16*1P.Deep Groove. Large Reel |
| 23 | M9D1NVM0000 | 16mm x 4mm Tape feeder. plastic W16*1P. eglar reel |
| 24 | M9D2CVM0000 | 16mm x 8mm Tape Feeder. Emboss. W16*2P.Large Reel |
| 25 | M9D2DVM0000 | 16mm x 8mm Tape Feeder. Emboss. W16*2P.Deep Groove. Large Reel |
| 26 | M9D2NVM0000 | 16mm x 8mm Tape feeder. plastic W16*2P. eglar reel |
| 27 | M9D3CVM0000 | 16mm x 12mm Tape Feeder. Emboss. W16*3P.Large Reel |
| 28 | M9D3DVM0000 | 16mm x 12mm Tape Feeder. Emboss. W16*3P.Deep Groove. Large Reel |
| 29 | M9D3NVM0000 | 16mm x 12mm Tape feeder. plastic W16*3P. eglar reel |
| 30 | M9D4CVM0000 | 16mm x 16mm tape Feeder. Emboss. W16*4P.large reel |
| 31 | M9D4DVM0000 | 16mm x 16mm Tape Feeder. Emboss. W16*4P.Deep Groove. Large Reel |
| 32 | M9E1CVM0000 | 24mm x 4mm Tape Feeder. Emboss. W24*1P.Large Reel |
| 33 | M9E1DVM0000 | 24mm x 4mm Tape Feeder. Emboss. W24*1P.Deep Groove. Large Reel |
| 34 | M9E2CVM0000 | 24mm x 8mm Tape Feeder. Emboss. W24*2P.Large Reel |
| 35 | M9E2DVM0000 | 24mm x 8mm Tape Feeder. Emboss. W24*2P.Deep Groove. Large Reel |
| 36 | M9E3CVM0000 | 24mm x 12mm Tape Feeder. Emboss. W24*3P.Large Reel |
| 37 | M9E3DVM0000 | 24mm x 12mm Tape Feeder. Emboss. W24*3P.Deep Groove. Large Reel |
| 38 | M9E4CVM0000 | 24mm x 16mm Tape Feeder. Emboss. W24*4P.Large Reel |
| 39 | M9E4DVM0000 | 24mm x 16mm Tape Feeder. Emboss. W24*4P.Deep Groove. Large Reel |
| 40 | M9E5CVM0000 | 24mm x 20mm Tape Feeder. Emboss. W24*5P.Large Reel |
| 41 | M9E5DVM0000 | 24mm x 20mm Tape Feeder. Emboss. W24*5P.Deep Groove. Large Reel |
| 42 | M9E6CVM0000 | 24mm x 24mm Tape Feeder. Emboss. W24*6P.Large Reel |
| 43 | M9E6DVM0000 | 24mm x 24mm Tape Feeder. Emboss. W24*6P.Deep Groove. Large Reel |
| 44 | M9F3CVM0000 | 32mm x 12mm Tape Feeder. Emboss. W32*3P.Large Reel |
| 45 | M9F3DVM0000 | 32mm x 12mm Tape Feeder. Emboss. W32*3P.Deep Groove. Large Reel |
| 46 | M9F4CVM0000 | 32mm x 16mm Tape Feeder. Emboss. W32*4P.Large Reel |
| 47 | M9F4DVM0000 | 32mm x 16mm Tape Feeder. Emboss. W32*4P.Deep Groove. Large Reel |
| 48 | M9F6CVM0000 | 32mm x 24mm Tape Feeder. Emboss. W32*6P.Large Reel |
| 49 | M9F6DVM0000 | 32mm x 24mm Tape Feeder. Emboss. W32*6P.Deep Groove. Large Reel |
| 50 | M9H2CVM0000 | 44mm x 8mm Tape Feeder. Emboss. W44*2P.Large Reel |
| 51 | M9H2DVM0000 | 44mm x 8mm Tape Feeder. Emboss. W44*2P.Deep Groove. Large Reel |
| 52 | M9H3CVM0000 | 44mm x 12mm Tape Feeder. Emboss. W44*3P.Large Reel |
| 53 | M9H3DVM0000 | 44mm x 12mm Tape Feeder. Emboss. W44*3P.Deep Groove. Large Reel |
| 54 | M9H4CVM0000 | 44mm x 16mm Tape Feeder. Emboss. W44*4P.Large Reel |
| 55 | M9H4DVM0000 | 44mm x 16mm Tape Feeder. Emboss. W44*4P.Deep Groove. Large Reel |
| 56 | M9H5CVM0000 | 44mm x 20mm Tape Feeder. Emboss. W44*5P.Large Reel |
| 57 | M9H5DVM0000 | 44mm x 20mm Tape Feeder. Emboss. W44*5P.Deep Groove. Large Reel |
| 58 | M9H6CVM0000 | 44mm x 24mm Tape Feeder. Emboss. W44*6P.Large Reel |
| 59 | M9H6DVM0000 | 44mm x 24mm Tape Feeder. Emboss. W44*6P.Deep Groove. Large Reel |
| 60 | M9H8CVM0000 | 44mm x 32mm Tape Feeder. Emboss. W44*8P.Large Reel |
| 61 | M9H8DVM0000 | 44mm x 32mm Tape Feeder. Emboss. W44*8P.Deep Groove. Large Reel |
| 62 | M9H9CVM0000 | 44mm x 36mm Tape Feeder. Emboss. W44*9P.Large Reel |
| 63 | M9H9DVM0000 | 44mm x 36mm Tape Feeder. Emboss. W44*9P.Deep Groove. Large Reel |
| 64 | M9J2DVM0000 | 56mm x 8mm Tape Feeder. Emboss. W56*2P.Deep Groove. Large Reel |
| 65 | M9J3DVM0000 | 56mm x 12mm Tape Feeder. Emboss. W56*3P.Deep Groove. Large Reel |
| 66 | M9J4DVM0000 | 56mm x 16mm Tape Feeder. Emboss. W56*4P.Deep Groove. Large Reel |
| 67 | M9J5DVM0000 | 56mm x 20mm Tape Feeder. Emboss. W56*5P.Deep Groove. Large Reel |
| 68 | M9J6DVM0000 | 56mm x 24mm Tape Feeder. Emboss. W56*6P.Deep Groove. Large Reel |
| 69 | M9J8DVM0000 | 56mm x 32mm Tape Feeder. Emboss. W56*8P.Deep Groove. Large Reel |
| 70 | M9J9DVM0000 | 56mm x 36mm Tape Feeder. Emboss. W56*9P.Deep Groove. Large Reel |
Panasonic/KME/Panasert CM120-MU CM20F-M CM201 CM202 CM301 M9 Type Adhesive Tape Feeder
| No. | Part No. | Unit Name / Part Name |
|---|---|---|
| 1 | M9G3CVM0000 | 32mm x 12mm Tape Feeder. Adhesive. W32*3P.Large Reel |
Panasonic/KME/Panasert CM120-MU CM20F-M CM201 CM202 CM301 M9 Tpye Double Tape Feeder
| No. | Part No. | Unit Name / Part Name |
|---|---|---|
| 1 | M9A1CWM0000 | 8mm x 4mm Tape Feeder. Emboss. W8*1P. Wide.Double Reel |
| 2 | M9A1NWM0000 | 8mm x 4mm Tape Feeder. Emboss. W8*1P. Double Reel |
| 3 | M9A5NWM0000 | 8mm x 2mm Tape Feeder. Emboss. W8*0.5P. Double Reel |
The Panasonic KME Panasert CM120-MU CM20F-M CM201 CM202 CM301 M9 Type Tape Feeder M9B5CSM0000 8mmx2mm W80.5P Large Reel (SKU: M9B5CSM0000.) is a premium-grade SMT spare component manufactured for high-speed pick and place machines. Designed for maximum durability and precision, this part is part of our extensive CM120 CM20/201/202/301 SMT Feeder, Panasonic SMT Spare Parts, Thru-hole Parts, SMD Feeders Sort by Size, SMD Paper Feeders, SMT Feeders – 8x2mm W8P2, SMT Feeders Sort by Type inventory. It ensures seamless integration and high efficiency on active PCB assembly lines.
How to use Panasonic KME Panasert CM120-MU CM20F-M CM201 CM202 CM301 M9 Type Tape Feeder M9B5CSM0000 8mmx2mm W80.5P Large Reel?
For optimal performance and durability, this component should be installed and calibrated by a certified SMT maintenance engineer. Regularly check the alignment, wear patterns, and vacuum suction parameters (for nozzles) to prevent component mispicks and ensure high assembly yields.
- Power down your mounter and disconnect the vacuum line.
- Clean the nozzle shaft or feeder mounting slot with ESD-safe cleaning alcohol.
- Carefully align the new component and tighten to the manufacturer's torque specifications.
- Perform a test cycle and verify the component alignment using mounter diagnostics before resuming full production.
