Panasert MPAV2B MCF MSF MPAG3 Ratchet Type Component Feeder 10488BF136 16*4mm Emboss

What is Panasert MPAV2B MCF MSF MPAG3 Ratchet Type Component Feeder 10488BF136 16*4mm Emboss?

SMTBOX is specialized in supply various kinds of spare parts for Panasonic MPAV2B MCF MSF MPAG3 series electronic component mounting  equipment. The following SMT feeders for Panasonic MPAV2B Pre-Owned Certified machine, we offer are original feeders made by Panasonic.

*Not every product can be priced on these pages, so please inquire about any items for a customized quote.

The MPAV2B machine’s 1-head 4-nozzle system enables “gang-pickup” of components. Placement speed is improved by the quality on-the-fly scan- recognition system with 3D and 2D sensors. With the self-indexing parts feeders, rapid tray lifters, and other advanced features, MPAV2B achieves tact time of 0.53 sec/piece for QFPs and 0.44 sec/ piece for chip components.

How to use Panasert MPAV2B MCF MSF MPAG3 Ratchet Type Component Feeder 10488BF136 16*4mm Emboss?

For optimal performance and durability, this component should be installed and calibrated by a certified SMT maintenance engineer. Regularly check the alignment, wear patterns, and vacuum suction parameters (for nozzles) to prevent component mispicks and ensure high assembly yields.

1. Power down your mounter and disconnect the vacuum line.
2. Clean the nozzle shaft or feeder mounting slot with ESD-safe cleaning alcohol.
3. Carefully align the new component and tighten to the manufacturer's torque specifications.
4. Perform a test cycle and verify the component alignment using mounter diagnostics before resuming full production.
