What is FUJI NXT Motor(Intelligent) Feeder 8mm UF01300 without Reel Holder?
Looking for FUJI NXT Motor(Intelligent) Feeder 8mm UF01300 without Reel Holder? This SMT spare part (SKU: UF01300., Brand: FUJI) is a high-precision component for SMT pick-and-place machines. Contact SMTBOX for competitive bulk prices, global delivery options, and fast RFQ turnaround.
FUJI NXT MOTOR Feeders without reel holder
| PartNo. | Description |
|---|---|
| UF01300 | W8 8mm without reel holder |
| UF01400 | W12 12mm without reel holder |
| UF01500 | W16 16mm without reel holder |
| UF01600 | W24 24mm without reel holder |
| UF01700 | W32 32mm without reel holder |
| UF01800 | W44 44mm without reel holder |
| UF01900 | W56 56mm without reel holder |
FUJI NXT MOTOR Feeders with reel holder
| PartNo. | Description |
|---|---|
| UF00400 | W8 8mm with 7″ reel holder |
| UF00500 | W8 8mm with15″ reel holder |
| UF00600 | W12 12mm with 7″ reel holder |
| UF00700 | W12 12mm with15″ reel holder |
| UF00800 | W16 16mm with15″ reel holder |
| UF00900 | W24 24mm with15″ reel holder |
| UF01000 | W32 32mm with15″ reel holder |
| UF01100 | W44 44mm with15″ reel holder |
| UF01200 | W56 56mm with15″ reel holder |
FUJI NXT III/IIIc ensures high compatibility with its predecessor NXT II. Many existing machine elements, such as placement heads, tray and feeder units, can be used even on the NXT III/IIIc.
Support the next generation component (03015) by the new, super-fast placement H24S (24 Nozzles, 35,000 CPH) and even faster feeders W08f.
The FUJI NXT Motor(Intelligent) Feeder 8mm UF01300 without Reel Holder (SKU: UF01300.) is a premium-grade SMT spare component manufactured for high-speed pick and place machines. Designed for maximum durability and precision, this part is part of our extensive FUJI SMD Spare Parts, FUJI SMT Feeders, SMD Feeders Sort by Size, SMD Intelligent Feeders, SMT Feeders – 8mm , SMT Feeders Sort by Type inventory. It ensures seamless integration and high efficiency on active PCB assembly lines.
How to use FUJI NXT Motor(Intelligent) Feeder 8mm UF01300 without Reel Holder?
For optimal performance and durability, this component should be installed and calibrated by a certified SMT maintenance engineer. Regularly check the alignment, wear patterns, and vacuum suction parameters (for nozzles) to prevent component mispicks and ensure high assembly yields.
- Power down your mounter and disconnect the vacuum line.
- Clean the nozzle shaft or feeder mounting slot with ESD-safe cleaning alcohol.
- Carefully align the new component and tighten to the manufacturer's torque specifications.
- Perform a test cycle and verify the component alignment using mounter diagnostics before resuming full production.
