FUJI NXT MOTOR Feeders without reel holder
| PartNo. | Description |
|---|---|
| UF01300 | W8 8mm without reel holder |
| UF01400 | W12 12mm without reel holder |
| UF01500 | W16 16mm without reel holder |
| UF01600 | W24 24mm without reel holder |
| UF01700 | W32 32mm without reel holder |
| UF01800 | W44 44mm without reel holder |
| UF01900 | W56 56mm without reel holder |
FUJI NXT MOTOR Feeders with reel holder
| PartNo. | Description |
|---|---|
| UF00400 | W8 8mm with 7″ reel holder |
| UF00500 | W8 8mm with15″ reel holder |
| UF00600 | W12 12mm with 7″ reel holder |
| UF00700 | W12 12mm with15″ reel holder |
| UF00800 | W16 16mm with15″ reel holder |
| UF00900 | W24 24mm with15″ reel holder |
| UF01000 | W32 32mm with15″ reel holder |
| UF01100 | W44 44mm with15″ reel holder |
| UF01200 | W56 56mm with15″ reel holder |
SMD SMT Nozzle for FUJI PTS-NXT-08JE H08 H12
| LNo. | Part No. | QTY | Description | Rating | Remarks |
|---|---|---|---|---|---|
| 1 | AA1AT04 | 1 | NOZZLE | R07-003-070 | N/A |
| 2 | AA05603 | 1 | NOZZLE | R07-004-070 | N/A |
| 3 | AA05703 | 1 | NOZZLE | R07-007-070 | N/A |
| 4 | AA05803 | 1 | NOZZLE | R07-010-070 | N/A |
| 5 | AA20A03 | 1 | NOZZLE | R07-013-070 | N/A |
| 6 | AA20B03 | 1 | NOZZLE | R07-018-070 | N/A |
| 7 | AA20C03 | 1 | NOZZLE | R07-025-070 | N/A |
| 8 | AA20D03 | 1 | NOZZLE | R07-037-070 | N/A |
| 9 | AA20E03 | 1 | NOZZLE | R07-050-070 | N/A |
| 10 | AA06404 | 1 | NOZZLE | R07-013M-070 | N/A |
| 11 | AA19G04 | 1 | NOZZLE | R07-018M-070 | N/A |
| 12 | AA06504 | 1 | NOZZLE | R07-025M-070 | N/A |
| 13 | AA0WT05 | 1 | NOZZLE | R07-025G-070 | N/A |
| 14 | AA18C02 | 1 | NOZZLE | R07-037G-070 | N/A |
| 14.1 | PB30310 | 1 | SHIM | N/A | N/A |
| 14.2 | H1194K | 1 | PAD,VACUUM | KPA-2-N | N/A |
| 15 | AA06302 | 1 | NOZZLE | R07-050G-070 | N/A |
| 15.1 | PB30310 | 1 | SHIM | N/A | N/A |
| 15.2 | H1339B | 1 | PAD,VACUUM | KPA-3.5-NOT | N/A |
SMD SMT Nozzle for FUJI PTS-NXT-08JE H04 PART1
| LNo. | PartNo. | QTY | Description | Rating | Remarks |
|---|---|---|---|---|---|
| 2 | AA06W07 | 1 | NOZZLE | R19-010-155 | N/A |
| 3 | AA06X08 | 1 | NOZZLE | R19-013-155 | N/A |
| 4 | AA06Y08 | 1 | NOZZLE | R19-018-155 | N/A |
| 5 | AA06Z09 | 1 | NOZZLE | R19-025-155 | N/A |
| 6 | AA07A09 | 1 | NOZZLE | R19-037-155 | N/A |
| 7 | AA07B08 | 1 | NOZZLE | R19-050-155 | N/A |
| 8 | AA07C06 | 1 | NOZZLE | R19-070-155 | N/A |
| 9 | AA07D05 | 1 | NOZZLE | R19-100-155 | N/A |
| 10 | AA07E06 | 1 | NOZZLE | R19-150-155 | N/A |
SMD SMT Nozzle for FUJI PTS-NXT-08JE H04 PART2
| LNo. | PartNo. | QTY | Description | Rating | Remarks |
|---|---|---|---|---|---|
| 1 | AA07F07 | 1 | NOZZLE | R19-025G-155 | N/A |
| 2 | AA07G05 | 1 | NOZZLE | R19-037G-155 | N/A |
| 2.1 | PB30310 | 1 | SHIM | N/A | N/A |
| 2.2 | H1194K | 1 | PAD,VACUUM | KPA-2-NOT | N/A |
| 3 | AA07H05 | 1 | NOZZLE | R19-050G-155 | N/A |
| 3.1 | PB30310 | 1 | SHIM | N/A | N/A |
| 3.2 | H1339B | 1 | PAD,VACUUM | KPA-3.5-NOT | N/A |
| 4 | AA07K05 | 1 | NOZZLE | R19-070G-155 | N/A |
| 4.1 | PB31591 | 1 | SHIM | N/A | N/A |
| 4.2 | PG01611 | 1 | PAD,VACUUM | N/A | N/A |
| 5 | AA07L05 | 1 | NOZZLE | R19-100G-155 | N/A |
| 5.1 | PB31600 | 1 | SHIM | N/A | N/A |
| 5.2 | PG01620 | 1 | PAD,VACUUM | N/A | N/A |
| 6 | AA07M07 | 1 | NOZZLE | R19-150G-155 | N/A |
| 6.1 | PB31611 | 1 | SHIM | N/A | N/A |
| 6.2 | PG01630 | 1 | PAD,VACUUM | N/A | N/A |
SMD SMT Nozzle for FUJI PTS-NXT-08JE H01 PART1
| LNo. | Part No. | QTY | Description | Rating | remarks |
|---|---|---|---|---|---|
| 1 | AA0AS05 | 1 | NOZZLE | R36-010-260 | N/A |
| 1.1 | A5188M | 1 | O RING | 9X0.8(FKM70) | N/A |
| 2 | AA06807 | 1 | NOZZLE | R36-013-260 | N/A |
| 3 | AA0HS02 | 1 | NOZZLE | R36-018-260 | N/A |
| 4 | AA0HT02 | 1 | NOZZLE | R36-025-260 | N/A |
| 5 | AA0HW02 | 1 | NOZZLE | R36-037-260 | N/A |
| 6 | AA0HX02 | 1 | NOZZLE | R36-050-260 | N/A |
| 7 | AA08008 | 1 | NOZZLE | R36-070-260 | N/A |
| 8 | AA08107 | 1 | NOZZLE | R36-100-260 | N/A |
| 9 | AA08207 | 1 | NOZZLE | R36-150-260 | N/A |
| 10 | AA08307 | 1 | NOZZLE | R36-200-260 | N/A |
| 11 | AA0MZ02 | 1 | NOZZLE | R36-013M-260 | N/A |
| 12 | AA11R02 | 1 | NOZZLE | R36-018M-260 | N/A |
| 13 | AA0ML03 | 1 | NOZZLE | R36-025M-260 | N/A |
SMD SMT Nozzle for FUJI PTS-NXT-08JE H01 PART2
| LNo. | PartNo. | QTY | Description | Rating | Remarks |
|---|---|---|---|---|---|
| 1 | AA08411 | 1 | NOZZLE | R36-025G-260 | N/A |
| 2 | AA08509 | 1 | NOZZLE | R36-037G-260 | N/A |
| 2.1 | PB30310 | 1 | SHIM | N/A | N/A |
| 2.2 | H1194K | 1 | PAD,VACUUM | KPA-2-NOT | N/A |
| 3 | AA07209 | 1 | NOZZLE | R36-050G-260 | N/A |
| 3.1 | PB30310 | 1 | SHIM | N/A | N/A |
| 3.2 | H1339B | 1 | PAD,VACUUM | KPA-3.5-NOT | N/A |
| 4 | AA07311 | 1 | NOZZLE | R36-070G-260 | N/A |
| 4.1 | PB31591 | 1 | SHIM | N/A | N/A |
| 4.2 | PG01611 | 1 | PAD,VACUUM | N/A | N/A |
| 5 | AA07410 | 1 | NOZZLE | R36-100G-260 | N/A |
| 5.1 | PB31600 | 1 | SHIM | N/A | N/A |
| 5.2 | PG01620 | 1 | PAD,VACUUM | N/A | N/A |
| 6 | AA07511 | 1 | NOZZLE | R36-150G-260 | N/A |
| 6.1 | PB31611 | 1 | SHIM | N/A | N/A |
| 6.2 | PG01630 | 1 | PAD,VACUUM | N/A | N/A |
| 7 | AA07610 | 1 | NOZZLE | R36-200G-260 | N/A |
| 7.1 | PB31731 | 1 | SHIM | N/A | N/A |
| 7.2 | PG01640 | 1 | PAD,VACUUM | N/A | N/A |
