KN610097135AA-11-1 NPM-D3 Inspection BOX N610097135AA

#1 . P/N: N210124371AD | Part name: Plate | Qty: 1

#2 . P/N: N210124041AD | Part name: Base Plate | Qty: 1

#3 . P/N: N210118626AA | Part name: Guide | Qty: 2

#4 . P/N: N210121927AA | Part name: Guide | Qty: 2

#5 . P/N: N210125131AA | Part name: Collar | Qty: 2

#6 . P/N: N210118655AB | Part name: Bracket | Qty: 3

#7 . P/N: N210124063AC | Part name: Cover | Qty: 1

#8 . P/N: N210125130AA | Part name: Bracket | Qty: 1

#9 . P/N: N210121402AA | Part name: Cover | Qty: 1

#10. P/N: N210124065AC | Part name: Rear Cover | Qty: 1

#11. P/N: N210124082AC | Part name: Cover | Qty: 1

#12. P/N: N210124389AA | Part name: Bracket | Qty: 2

#13. P/N: N610097161AB | Part name: Bush | Qty: 1

#14. P/N: N510052984AA | Part name: Cap | Remarks:CP-328-B-5-G hole process gray | Qty: 42

#15. P/N: N510045731AA | Part name: Caster | Remarks:413SA-UB 50mm | Qty: 2

#16. P/N: N510045733AA | Part name: Caster | Remarks:420SA-UB 50mm | Qty: 2

#17. P/N: N510049422AA | Part name: Spacer | Remarks:3382330-50025 | Qty: 6

#18. P/N: N510052316AA | Part name: Urethane | Remarks: 87AZFH-D24-V7-H4-G12-L11 | Qty: 2

#20. P/N: N510050630AA | Part name: Frame | Remarks:SFF-304B L=407 | Qty: 4

#21. P/N: N510049429AA | Part name: Frame | Remarks:SFF-304B L=450 | Qty: 2

#22. P/N: N510014679AA | Part name: Frame | Remarks:SFF-304B L=340 | Qty: 2

#23. P/N: N510005830AA | Part name: Bracket | Remarks:SFJ-018B | Qty: 22

#24. P/N: N510013440AA | Part name: Nut | Remarks:SFN-AS5 | Qty: 37

#25. P/N: KXF0DWJ9A00 | Part name: Support | Remarks:SFA-9A2 | Qty: 75

#26. P/N: N510013438AA | Part name: Nut | Remarks:SFN-AS6 | Qty: 36

#27. P/N: N510056668AA | Part name: Grommet | Remarks:C-30-SG-42A-EP-UL | Qty: 2

#28. P/N: N510009129AA | Part name: Spacer | Remarks:SFJ-401S | Qty: 8

#29. P/N: N510013304AA | Part name: Nut | Remarks:SFN-LS5 | Qty: 24

#30. P/N: N510057510AA | Part name: Cap | Remarks:SFA-033B | Qty: 4

#31. P/N: N510050631AA | Part name: Frame | Remarks:SFF-304B L=504 | Qty: 2

#32. P/N: N510052597AA | Part name: Adjust Bolt | Remarks:D-C12X75 | Qty: 2

#33. P/N: N510013441AA | Part name: Nut | Remarks:SFN-AS4 | Qty: 2

#34. P/N: N510017630AA | Part name: Bolt | Remarks: Hexagon socket Flat head bolt M5X12-10.9 A2J (Trivalent) | Qty: 34

#36. P/N: N510017632AA | Part name: Bolt | Remarks: Hexagon socket Flat head bolt M5X16-10.9 A2J (Trivalent) | Qty: 8

#37. P/N: N510045728AA | Part name: Clamp | Remarks:UL-23 | Qty: 2

#38. P/N: N510018158AA | Part name: Screw | Remarks:Cross recessed Countersunk head machine screw M3X6-4.8 A2J (Trivalent) | Qty: 2

#39. P/N: N510017905AA | Part name: Nut | Remarks:Hexagon nut Type-1 Best class M16-6H-4T A2J (Trivalent) | Qty: 4

#40. P/N: N510018509AA | Part name: Washer | Remarks:Round finish plain washer 16 10H A2J (Trivalent) | Qty: 4

#41. P/N: N510048517AA | Part name: Cable Support | Remarks: FT4 | Qty: 15
