#1. P/N: FC30-001272A | Part name: Plate Center Duct L | Qty: 1
#2. P/N: FC18-001182 | Part name: Spacer Asl 310E | Qty: 2
#3. P/N: FC30-001271A | Part name: Plate Center Duct R | Qty: 1
#4. P/N: FC09-002009A | Part name: Bracket Conector A Spcc Pfznni W | Qty: 2
#5. P/N: FC09-002010A | Part name: Bracket Pipe Guide Spcc Pfznni W | Qty: 1
#6. P/N: FC09-002008A | Part name: Bracket Conector Spcc Pfznni W | Qty: 1
#7. P/N: FC15-001141A | Part name: Cover Main Spcc Pfznni W | Qty: 1
#8. P/N: FC18-000114A | Part name: Stud Support Stud S25 25 Me1:Steel | Qty: 4
#9. P/N: EP06-001012 | Part name: Servo Control Drive D4910V121 | Qty: 1 | Old P/N: EP06-000210 / EP06-000472 / EP06-001006
#10. P/N: FC15-001426A | Part name: Cover Front Cover Hp | Qty: 1
#11. P/N: HP13-000009 | Part name: Tube Tube Web8604 (10M) Pl24:Silicon | Qty: 2
#12. P/N: FC38-000061A | Part name: Spring Spring Z Swp B | Qty: 2
#13. P/N: HP13-900032 | Part name: Tube Tu0425W | Qty: 1
#14. P/N: HP13-000019 | Part name: Tube Tube Tu0425B | Qty: 1
#15. P/N: FC18-001187 | Part name: Spacer Asb 336E | Qty: 1
#16. P/N: FC09-002013A | Part name: Bracket Conector C Spcc Pfznni W | Qty: 1
#17. P/N: FC09-002011A | Part name: Bracket Spring Spcc Pfznni W | Qty: 1
#18. P/N: FC18-001182 | Part name: Spacer Asl 310E | Qty: 2
#19. P/N: FC18-001378 | Part name: Bolt Cbsa4 10 Cbsa4 10 M4 10 | Qty: 2
#20. P/N: FC18-000931 | Part name: Spacer Spacer | Qty: 2
#21. P/N: FC09-002012A | Part name: Bracket Spring B Spcc Pfznni W | Qty: 1
#22. P/N: FC18-901046 | Part name: Hex Nut [M4 (Bl/Zn)] | Qty: 2 | Remarks: Nut[M4]
