Electrical Box Section For Head Section on Yamaha Hitachi Chip Mounting System HH-G300 High Speed Head Unit

GXH-3 4Unit/1Machine
GXH-3J 2Unit/1Machine
#1. P/N: 630 123 5523 | Unit Driver -A31 Mr-Md08
#2. P/N: 630 126 8064 | Pipe Fittings Kq2L06-M5
#3. P/N: 630 125 0212 | Pipe Fittings Kq2H04-M5
#4. P/N: 630 125 0618 | Solenoid Valve -Y0902
#8. P/N: 630 159 8796 | Bracket
#9. P/N: 630 159 9069 | Cover
#10. P/N: 630 159 8994 | Support
#11. P/N: 630 159 9007 | Support
#12. P/N: 630 161 3055 | Box
#13. P/N: 630 159 8994 | Support
#14. P/N: 630 159 9007 | Support
#20. P/N: 630 162 2170 | Base
#51. P/N: 630 159 2534 | P.C.B Mount -U25
#59. P/N: 630 087 6659 | Bolt Hex-Sct M2X10
#61. P/N: 630 000 7503 | Bolt Hex-Sct M3X6
#66. P/N: 630 000 7619 | Bolt Hex-Sct M4X8
#67. P/N: 630 000 7626 | Bolt Hex-Sct M4X10
#70. P/N: 630 067 0240 | Bolt
#71. P/N: 630 127 4546 | Scr Pan+Sw+W 3X6 19
#72. P/N: 6301517230 | Machine Screw
#74. P/N: 411 141 2608 | Washer Spr
#76. P/N: 411 141 2806 | Washer Spr
#77. P/N: 411 141 2905 | Washer Spr 12
#79. P/N: 411 141 6903 | Washer V 2X5X0.3
#81. P/N: 411 141 3902 | Washer V 3X7X0.5
#82. P/N: 411 141 4008 | Washer V 4X9X0.8
