Frame Section and Tape Driving Section on Hitachi SMT Tape Feeder Part List of GT-12161B GD-12161B

#1. P/N: 630 160 9898 | Frame

#2. P/N: 630 152 6775 | Block(Kiban)

#3. P/N: 630 127 4706 | Cover(La)

#4. P/N: 630 160 9850 | Cover(Lb)

#5. P/N: 630 127 4775 | Cover(Lc)

#6. P/N: 630 160 9867 | Cover(R)

#8. P/N: 630 146 8976 | Cover(Kiban)

#9. P/N: 630 136 6463 | Slide(Base)

#10. P/N: 630 126 6084 | Assy,Lever(Kaijyo)

#11. P/N: 630 126 5827 | Pin,Hinge

#12. P/N: 630 126 5834 | Roller

#13. P/N: 630 126 5841 | Pin,Guide(Roller)

#14. P/N: 630 164 6121 | Spring,Torsion

#19. P/N: 630 127 4867 | Cover(Haisen)

#20. P/N: 630 126 5926 | Pin,Locate(Tape)

#23. P/N: 630 161 0269 | Cover(Futa)

#24. P/N: 630 128 7577 | Mech Parts(Magnet)

#25. P/N: 630 126 5902 | Mech Parts(Cutter)

#26. P/N: 630 127 4546 | Scr Pan+Sw+W 3X6

#27. P/N: 630 034 7906 | Mech Parts(Rubber Legs)

#28. P/N: 411 033 5700 | Scr Flt 2.5X6 34 877G–010-028

#29. P/N: 630 000 8494 | Bolt,Hex-Sct M2.5X6

#30. P/N: 630 000 7633 | Bolt,Hex-Sct M4X12

#32. P/N: 411 140 7208 | Scr Flt 4X6

#33. P/N: 411 125 5403 | Scr Pan 2X4

#37. P/N: 411 001 0003 | Ring E

#40. P/N: 411 141 2905 | Washer Spr

#41. P/N: 411 141 2509 | Washer Spr

#42. P/N: 411 141 4008 | Washer V 4X9X0.8

#43. P/N: 411 141 3605 | Washer V 2X5X0.3

#46. P/N: 630 128 0127 | Name Plate,Notice

#47. P/N: 630 159 3722 | Name Plate,Index

#68. P/N: 630 133 0273 | Mech Parts

#69. P/N: 630 160 9874 | Pin,Locate

#70. P/N: 630 125 9970 | Spring Pin

#71. P/N: 630 162 9940 | Set Screw M2X2(Awp)

#74. P/N: 630 134 2634 | Name Plate,Index

#101.P/N: 630 155 4495 | Assy,Gear

#101-03. P/N: 630 144 3935 | Collar(Bearing)

#101-06. P/N: 630 149 1332 | Pulley,Timing

#101-07. P/N: 630 126 8248 | Set Screw(Set Screw) M2X3

#103. P/N: 630 158 4270 | Assy,Gear

#104. P/N: 630 156 8591 | Assy,Sprocket

#106. P/N: 630 127 4966 | Holder

#107. P/N: 630 126 4912 | Pin,Locate

#121. P/N: 630 127 6199 | Belt,Timing

#122. P/N: 630 126 5988 | Pin,Locate

#123. P/N: 630 008 3804 | Washer

#124. P/N: 630 008 3057 | Bolt,Hex-Sct M2X4

#125. P/N: 630 087 6659 | Bolt,Hex-Sct M2X10

#126. P/N: 630 000 7527 | Bolt,Hex-Sct M3X10

#127. P/N: 630 000 7534 | Bolt,Hex-Sct M3X12

#129. P/N: 411 141 2806 | Washer Spr

#130. P/N: 411 141 3902 | Washer V 3X7X0.5

#139. P/N: 630 154 9705 | Assy,Motor,Ac-Servo
