#1 P/N: J7053679A | Part Name: PCB GUIDE END | Qty: 2
#2 P/N: J7053785a | Part Name: PCB GUIDE F.C | Qty: 1
#3 P/N: J7153401A | Part Name: CONVEYOR FRONT FRAME | Qty: 1
#4 P/N: J7153399A | Part Name: CLAMP FRONT FRAME | Qty: 1
#5 P/N: J7053665A | Part Name: WAIT PULLEY BKT SF | Qty: 2
#6 P/N: J7053666A | Part Name: BEARING HOUSING SF | Qty: 3
#7 P/N: J7053034A | Part Name: BEARING NUT-SF | Qty: 3
#8 P/N: J3109002A | Part Name: SPEED CONTROL MOTOR | Qty: 2 | Type: S6106GA-S (SUNG-SIN)
#9 P/N: J7153414A | Part Name: AC MOTOR PULLEY | Qty: 2
10 P/N: J6602081A | Part Name: TIMING BELT -AC MOTOR | Qty: 2 | Type: 237-S3M-6
11 P/N: J7053776A | Part Name: SPACER -AC MOTOR | Qty: 4
12 P/N: J7053009A | Part Name: IDLER SHAFT-S2 | Qty: 9
13 P/N: J7253007A | Part Name: IDLER 2 | Qty: 8
14 P/N: J7053047A | Part Name: IDLER SPACER-S | Qty: 9
15 P/N: J7253006A | Part Name: IDLER | Qty: 1 | Type: | Qty: 4
16 P/N: J7053048A | Part Name: IDLER SPACER-M | Qty: 3
17 P/N: J7053050A | Part Name: IDLER SHAFT-M | Qty: 3
18 P/N: J6607016A | Part Name: LM SLIDE | Qty: 2 | Type: BSP 1025
19 P/N: J7153036A | Part Name: SLIDE GUIDE | Qty: 1
20 P/N: J7153034A | Part Name: CLAMP SHAFT | Qty: 2
21 P/N: J7153010B | Part Name: ADJUST SHAFT | Qty: 2
22 P/N: J7253008A | Part Name: STOPPER | Qty: 2
23 P/N: J7053708A | Part Name: SENSOR BKT S1 | Qty: 2
24 P/N: J3211033A | Part Name: PHOTO SENSOR | Qty: 2 | Type: E3S-LS3N
25 P/N: J6602080A | Part Name: TIMING BELT -STEP MOTOR | Qty: 1 | Type: 201-S3M-6
26 P/N: J7053782A | Part Name: SPLINE S | Qty: 2
27 P/N: J7153110A | Part Name: FLAT PULLEY -AC MOTOR | Qty: 2
28 P/N: J7153413A | Part Name: PULLEY-SPLINE | Qty: 3
29 P/N: J7053684A | Part Name: STOPPER TOP PLATE | Qty: 1
30 P/N: J6701018B | Part Name: STOPPER CYLINDER 1 | Qty: 1 | Type: WTS10*30-RS2
31 P/N: J6703007A | Part Name: THROTTLE VALVE(ELBOW) | Qty: 1 | Type: AS1201F-M5-04-X214/JNC4-M5
32 P/N: J6711001A | Part Name: ELBOW FITTING | Qty: 1 | Type: KQ2L04-M5/PL4-M5M/SQL04-M5
33 P/N: J7053685A | Part Name: STOPPER BRACKET-M | Qty: 1
34 P/N: J7053769A | Part Name: BRACKET-MOTOR | Qty: 1
35 P/N: J3104013A | Part Name: C/V STEP MOTOR | Qty: 1 | Type: 4S56Q-03076S
36 P/N: J7053767A | Part Name: SPLINE-M | Qty: 1
37 P/N: J7153417A | Part Name: PULLEY-STEP MOTOR | Qty: 1
38 P/N: J7153405A | Part Name: FLAT PULLEY-STEP | Qty: 1
39 P/N: J6601122A | Part Name: BEARING | Qty: 5 | Type: 6901ZZ
40 P/N: J6073020050S | Part Name: C-RING (SHAFT) | Qty: 3 | Type: DIA12(SUS)
41 P/N: J7053205A | Part Name: S-MOTOR BRACKET | Qty: 1
42 P/N: J7053775A | Part Name: BKT-AC MOTOR | Qty: 2
43 P/N: J6602082A | Part Name: FLAT BELT-END ZONE | Qty: 2 | Type: MAM-5P, 1230L, 7W
44 P/N: J6602083A | Part Name: FLAT BELT-WORK ZONE | Qty: 1 | Type: MAM-5P, 1534L, 7W
45 P/N: J7253009B | Part Name: STOPPER 2 | Qty: 2
46 P/N: J6073000036H | Part Name: C-RING | Qty: 2 | Type: 10MM (HOLE)
47 P/N: J6601016A | Part Name: BALL BUSH | Qty: 4 | Type: LM 5(M)
48 P/N: J7153033A | Part Name: BUSH SPACER | Qty: 2
49 P/N: J7053184A | Part Name: SQUARE NUT M4 | Qty: 9
