Base Frame (2/2) on Hanwha (Samsung Techwin) Excellent Modular EXCEN PRO (D) (M) (L)

Base Frame (2/2) on Hanwha (Samsung Techwin) Excellent Modular EXCEN PRO (D) (M) (L)

#1. P/N: EP06-900166 | Part name: Kollmorgen Driver S20360 Srs | Qty: 2

#2. P/N: EP06-900156 | Part name: X Axis Kollmorgen Driver S20660 Srs | Qty: 2

#3. P/N: FC09-000762B | Part name: Bracket Valve Bkt | Qty: 1

#4. P/N: AM03-000069 | Part name: Manifold Vqz335R 00 Cjpz0967 | Qty: 1

#5. P/N: HP09-000105 | Part name: Regulator Regulator Ar20 02Bg 1Ry 0.2Mpa | Qty: 1

#6. P/N: AM03-000070 | Part name: Assy Air Vp Blow Reg Assy | Qty: 2

#7. P/N: FC09-002522A | Part name: Bracket Regulator Bkt | Qty: 1

#8. P/N: AM03-000068 | Part name: Assy Air Vp Main Reg Assy | Qty: 1

#9. P/N: HP14-000192 | Part name: Valve Solenoid Solvalve Anc | Qty: 1 | Old P/N: EP07-000833 | Remarks: ASSY

#9. P/N: HP14-002056 | Part name: Valve Solenoid Dv1120 5V T4 | Remarks: Single Valve

#10. P/N: HP14-000193 | Part name: Valve Solenoid Solvalve Cc Cut | Qty: 2 | Old P/N: EP07-000834 | Remarks: ASSY

#10. P/N: HP14-002057 | Part name: Valve Solenoid Dv1120 5V T6 | Remarks: Single Valve

#10. P/N: HP14-000216 | Part name: Solenoid Solvalve Dv1220 5V T6 | Remarks: Single Valve

#11. P/N: AM03-007437A | Part name: Electric V1P Power Unit Assy | Qty: 1

#12. P/N: AM03-009553J | Part name: Base Control Board | Qty: 1 | Old P/N: AM03-009553G / AM03-009553H / AM03-009553I

#13. P/N: EP18-000005 | Part name: Relay G9Sc 400 Cnp4Edc24 4Pole 24V 15Ma | Qty: 2

#14. P/N: EP06-901019 | Part name: Ada600F 48 | Qty: 2

#15. P/N: EP07-901337 | Part name: Sd Q19 Dc24V1A1B | Qty: 2

#16. P/N: EP07-901338 | Part name: Sd Q11 Dc24V1B | Qty: 1

#17. P/N: EP06-000526 | Part name: Supply Power Ac Dc Ada750F 24 F 220Vac 2 | Qty: 1 | Old P/N: EP06-000232

#18. P/N: EP06-901047 | Part name: Pba15F 24 N | Qty: 1

#19. P/N: EP07-900053 | Part name: Cp T4 | Qty: 1

#20. P/N: EP07-900049 | Part name: Cp31Fi/5(Ccc) | Qty: 1

#21. P/N: FC09-004278A | Part name: Cable Guide | Qty: 1

#22. P/N: AM03-014955A | Part name: Assy Board Gioex Board Assy | Qty: 1 | Old P/N: AM03-009555A

#23. P/N: AM03-000678A | Part name: Output Connector Board | Qty: 2

#24. P/N: AM03-000677A | Part name: Input Connector Board | Qty: 7

#25. P/N: FC09-001943B | Part name: Io Board Bkt | Qty: 1

#26. P/N: AM03-017098A | Part name: Base Side Cover | Qty: 1

#27. P/N: AM03-008041A | Part name: Assy Main Frame Foot 950 Assy | Qty: 6

#28. P/N: AM03-001107 | Part name: Assy Air Cleaning Blow Ar20 02 Cjtz3274 | Qty: 1

#28. P/N: FC09-002108B | Part name: Bracket Mounting V1P50 Pu Cover 12Cb | Qty: 1

#29. P/N: FC09-007476A | Part name: Bracket Mtv1Pp Cyl But Cont Bkt | Qty: 1
