Having issues with X/Y Limit Was Not Detected Of X-Axis Frame on Samsung Techwin SM321 SMT Component Assembly Machine? Read our step-by-step SMT maintenance solution below. If you require replacement feeders, nozzles, or sensors, contact SMTBOX for OEM-compatible parts.
Possible Cause:
1. Defective home sensor position/movement
Measures
1) Check the position and movement of the sensor
2) Axis Sensor Board (Check J9060162A)
– CN1 : Y1 Home / Y1 + Limit /Y1-Limit
– CN3 : X Home / X +Limit / X -Limit
Remarks: Rack Assembly, Cableway.
2. Defective coupling connection
Measures: Check the connection status of the coupling
3. Defective motor/motor driver
Measures: Check and replace the motor driver. (Check after replacement with other motor driver)
Remarks: Motor and driver
4. Defective coupling connection
Measures: Reconnect the coupling.
