What is Panasonic BM221 BM123 BM231 Nozzle M 10807GH813AF?
Looking for Panasonic BM221 BM123 BM231 Nozzle M 10807GH813AF? This SMT spare part (SKU: 10807GH813AF., Brand: Panasonic) is a high-precision component for SMT pick-and-place machines. Contact SMTBOX for competitive bulk prices, global delivery options, and fast RFQ turnaround.
We offer Panasonic BM221 BM123 BM231 Nozzle M 10807GH813AF. Please contact sales@smtbox.com
| Ref. No. | Nozzle Type | Part Number |
| NOZZLE Section | ||
| 1 | SX | 10862GH810AA |
| 2 | SA | 10807GH811AG |
| 3 | S | 10807GH812AG |
| 4 | M | 10807GH813AF |
| 5 | ML | 10807GH814AF |
| 6 | MG | 10807GC007 |
| 7 | MG-P | 10807GC008AA |
| 8 | LA | 10807GH815AF |
| 9 | L(SHORT) | 10817GC800AG |
| 10 | M | 10817GC834AF |
| 11 | MELF | 10807GJ813AL |
| CNT NOZZLE Section | ||
| 1 | S | 10807GH817AF |
| 2 | M | 10807GH818AF |
| 3 | M(SHORT) | 10817GC802AG |
| 4 | CN-R1 | 10817GA822AG |
| 5 | CN-R2 | 10817GA844AG |
| 6 | CN-R3 | 10817GH819AF |
| 7 | CN-R4 | 10807GH820AF |
| 8 | CN-R5 | 10807GH821AF |
| 9 | CN-R6 | 10807GH822AF |
| 10 | CN-R7 | 10817GA861AG |
| 11 | CN-R8 | 10807GH823AF |
| 12 | CN-R9 | 10817GA862AG |
| 13 | CN-R10 | 10817GJ829AG |
| 14 | CN-R11 | 10807GH824AF |
| 15 | CN-R12 | 10807GH825AF |
The Panasonic BM221 BM123 BM231 Nozzle M 10807GH813AF (SKU: 10807GH813AF.) is a premium-grade SMT spare component manufactured for high-speed pick and place machines. Designed for maximum durability and precision, this part is part of our extensive Panasonic SMT Nozzle, Panasonic SMT Spare Parts, Thru-hole Parts inventory. It ensures seamless integration and high efficiency on active PCB assembly lines.
How to use Panasonic BM221 BM123 BM231 Nozzle M 10807GH813AF?
For optimal performance and durability, this component should be installed and calibrated by a certified SMT maintenance engineer. Regularly check the alignment, wear patterns, and vacuum suction parameters (for nozzles) to prevent component mispicks and ensure high assembly yields.
- Power down your mounter and disconnect the vacuum line.
- Clean the nozzle shaft or feeder mounting slot with ESD-safe cleaning alcohol.
- Carefully align the new component and tighten to the manufacturer's torque specifications.
- Perform a test cycle and verify the component alignment using mounter diagnostics before resuming full production.
