Tape Driving Section: Hitachi SMT Tape Feeder Part List of GT-18080B, 18081B, 18082B, 18083B

#101 P/N: 630 155 4167 | Assy Gear(Worm)

#101-03 P/N: 630 126 5964 | Collar(Pulley)

#101-04 P/N: 630 126 5971 | Collar(Bearing)

#101-07 P/N: 630 125 4692 | Pulley Timing

#101-08 P/N: 630 126 8248 | Set Screw(Set Screw) | Type: M2X3 SET

#102 P/N: 630 155 4488 | Assy Gear

#102-03 P/N: 630 126 5964 | Collar(Pulley)

#102-04 P/N: 630 126 5971 | Collar(Bearing)

#102-07 P/N: 630 125 4692 | Pulley Timing

#102-08 P/N: 630 126 8248 | Set Screw(Set Screw) | Type: M2X3 SET

#103 P/N: 630 158 4263 | Assy Gear

#104 P/N: 630 156 8560 | Assy Sprocket

#105 P/N: 630 156 8577 | Assy Sprocket

#106 P/N: 630 126 4905 | Holder

#107 P/N: 630 126 4912 | Pin Locate

#108 P/N: 630 128 2145 | Collar(Sprocket)

#108 P/N: 630 128 2152 | Collar(Sprocket)

#108 P/N: 630 128 2169 | Collar(Sprocket)

#109 P/N: 630 126 5759 | Cover(Worm-A)

#110 P/N: 630 126 5766 | Cover(Worm-B)

#111 P/N: 630 138 3521 | Cover(Worm-C)

#112 P/N: 630 126 5780 | Cover(Worm-D)

#113 P/N: 630 165 3884 | Cap(Cap)

#121 P/N: 630 125 4708 | Belt Timing

#122 P/N: 630 126 5988 | Pin Locate

#123 P/N: 630 008 3804 | Washer

#124 P/N: 630 008 3057 | Bolt Hex-Sct | Type: M2X4

#126 P/N: 630 000 7510 | Bolt Hex-Sct | Type: M3X8

#127 P/N: 630 000 7534 | Bolt Hex-Sct | Type: M3X12

#129 P/N: 411 141 2806 | Washer Spr

#130 P/N: 411 141 3902 | Washer V 3X7X0.5

#139 P/N: 630 154 9705 | Assy Motor Ac-Servo | Type: M01, M02

Notice：The Key No. 103, 104, 105 and 113 (with a circle) are maintenance components. For replacement timing, refer to the Instruction Manual or consult our service personnel.
