Cover Tape Winding Section of Hitachi SMT Tape Feeder Part List of GT-18080B GT-18081B GT-18082B GT-18083B

#201 P/N: 630 167 0683 | Assy Gear

#201-01 P/N: 630 158 2740 | Assy Base(L)

#201-02 P/N: 630 166 9144 | Gear(Hira-2)

#201-03 P/N: 630 155 1449 | Gear

#201-04 P/N: 630 162 2576 | Cover(Makitori-2)

#201-05 P/N: 630 134 7011 | Pin Locate(Siten-1)

#201-06 P/N: 411 125 5403 | Scr Pan 2X4

#201-07 P/N: 411 141 2509 | Washer Spr 2

#201-08 P/N: 411 131 5305 | Washer F 2X4.3X0.3

#201-09 P/N: 630 149 2612 | Cover

#202 P/N: 630 167 0690 | Assy Gear

#202-01 P/N: 630 158 2757 | Assy Base(R)

#202-02 P/N: 630 166 9144 | Gear(Hira-2)

#202-03 P/N: 630 155 1449 | Gear

#202-04 P/N: 630 162 2576 | Cover(Makitori-2)

#202-05 P/N: 630 134 7011 | Pin Locate(Siten-1)

#202-06 P/N: 411 125 5403 | Scr Pan 2X4

#202-07 P/N: 411 141 2509 | Washer Spr 2

#202-08 P/N: 411 131 5305 | Washer F 2X4.3X0.3

#202-09 P/N: 630 149 2605 | Cover

#207 P/N: 630 166 4101 | Assy Lever(Kaijo-L)

#207-01 P/N: 630 166 3005 | Assy Lever(Kaijo-L)

#207-02 P/N: 630 165 6298 | Gear(Hira-1)

#207-03 P/N: 630 165 6281 | Pin Locate(Sitenn-1)

#207-04 P/N: 630 165 6359 | Block(L)

#207-05 P/N: 411 033 5700 | Scr Flt 2.5X6

#207-06 P/N: 411 140 6201 | Scr Pan 2.5X6

#207-07 P/N: 411 141 2707 | Washer Spr 2.5

#207-08 P/N: 411 141 5609 | Washer F 2.5X5X0.5

#208 P/N: 630 166 4095 | Assy Lever(Kaijo-R)

#208-01 P/N: 630 166 2992 | Assy Lever(Kaijo-R)

#208-02 P/N: 630 165 6298 | Gear(Hira-1)

#208-03 P/N: 630 165 6281 | Pin Locate(Sitenn-1)

#208-04 P/N: 630 165 6366 | Block(R)

#208-05 P/N: 411 033 5700 | Scr Flt 2.5X6

#208-06 P/N: 411 140 6201 | Scr Pan 2.5X6

#208-07 P/N: 411 141 2707 | Washer Spr 2.5

#208-08 P/N: 411 141 5609 | Washer F 2.5X5X0.5

#210 P/N: 411 141 0000 | Nut Hex 3

#213 P/N: 630 126 6374 | Spring Comp

#214 P/N: 630 160 8372 | Assy Lever(Makitori-L)

#215 P/N: 630 160 8389 | Assy Lever(Makitori-R)

#216 P/N: 630 126 6619 | Roller(A)

#218 P/N: 630 126 6596 | Pin Guide

#219 P/N: 630 126 6381 | Spring Comp

#220 P/N: 630 126 6602 | Pin Guide(Bane)

#221 P/N: 630 126 7715 | Motor Dc | M91 M92 #LN-18-01801

#224 P/N: 630 126 5988 | Pin Locate

#227 P/N: 630 165 6311 | Pin Locate(Siten-2)

#228 P/N: 630 000 8494 | Bolt Hex-Sct | M2.5X6

#229 P/N: 630 000 7503 | Bolt Hex-Sct | M3X6

#232 P/N: 411 016 0203 | Ring E 2.5

#233 P/N: 630 126 8248 | Set Screw(Set Screw) | M2X3 SET

#234 P/N: 411 141 6606 | Washer Spr 2.5

#235 P/N: 411 141 2806 | Washer Spr 3

#236 P/N: 411 141 5708 | Washer F 2.5X5X0.5

#237 P/N: 411 141 3902 | Washer V 3X7X0.5

#242 P/N: 630 126 1621 | Sensor Photo | B03 B04 #EE-SX3144-P2

#245 P/N: 411 140 6300 | Scr Pan 2X8

Notice: The Key No. 201, 202, 207, 208, 214, 215, 216 and 221 (with a circle) are maintenance components. For replacement timing, refer to the Instruction Manual or consult our service
personnel.
