Splicing Detection Unit DS-08080 for Hitachi Yamaha Motorized 8mm Tape Feeder

#1. P/N: 630 155 6802 | Frame

#2. P/N: 630 130 0542 | Assy Lever(Hold)

#3. P/N: 630 129 5886 | Cover

#4. P/N: 630 129 5879 | Spring Torsion

#5. P/N: 411 016 0203 | Ring E 2.5

#6. P/N: 630 128 9021 | Sensor Photo B01 B02 #EE-SPY424-P1

#7. P/N: 411 039 2604 | Scr Pan 2X6

#8. P/N: 411 141 2509 | Washer Spr

#9. P/N: 411 141 3605 | Washer V 2X5X0.3

#10. P/N: 411 033 5700 | Scr Flt 2.5X6

#11. P/N: 630 000 7664 | Bolt Hex-Sct M4X20

#12. P/N: 411 141 2905 | Washer Spr 4

#13. P/N: 411 141 4008 | Washer V 4X9X0.8

#14. P/N: 630 132 2087 | Name Plate Index

#15. P/N: 630 143 4346 | Name Plate Index

#16. P/N: 630 140 3694 | Guide
