NPM Test Dispense Unit Dispenser Head N610092665AA

#1. P/N: N210135216AB | Part name: Base | Qty: 1

#2. P/N: N210131679AC | Part name: Plate | Qty: 1

#4. P/N: N210135218AA | Part name: Block | Qty: 1

#5. P/N: N210092269AC | Part name: Block | Qty: 1

#6. P/N: N210092268AD | Part name: Block | Qty: 1

#8. P/N: N210111278AB | Part name: Plate | Qty: 1

#9. P/N: N210135219AA | Part name: Bracket | Qty: 1

#10. P/N: N210145181AA | Part name: Bracket | Qty: 1

#11. P/N: N510057419AA | Part name: Linear Way | Remarks: LWL5C1R45E523 | Qty: 1

#12. P/N: N510017252AA | Part name: Bolt | Remarks: Hexagon socket head cap screw M2.6X8-10.9 A2J (Trivalent) | Qty: 2

#14. P/N: N510020589AA | Part name: Pin | Remarks: MMS3-8 | Qty: 6

#15. P/N: N510024882AA | Part name: Spacer | Remarks: CB-303E | Qty: 2

#16. P/N: KXF0525AA00 | Part name: Pin | Remarks: SPP2-6 | Qty: 2

#17. P/N: N510032513AA | Part name: Bolt | Remarks: MMSB4.5-25 | Qty: 1

#18. P/N: N510020196AA | Part name: Spacer | Remarks: CB-310E | Qty: 1

#19. P/N: N510017093AA | Part name: Spacer | Remarks: CB-315E | Qty: 1

#20. P/N: N610114116AA | Part name: Rack | Qty: 1

#21. P/N: N510052370AA | Part name: Spring | Remarks: C148 | Qty: 1
