Panasonic NPM-D3 Power Unit 1 N610161320AA

Panasonic Npm D3 Power Unit N610161320AA KN610161320AA

#1. P/N: N610161195AA | Part name: Trestle Transportation Control Ilk Pcb | Qty: 1

#2. P/N: N610059330AA | Part name: Power Failure Sub Board | Remarks: PNF0AN-AA | Qty: 1

#3. P/N: N210191972AA | Part name: Filter | Qty: 1

#4. P/N: N210110264AA | Part name: Spring | Qty: 1

#5. P/N: N510068347AA | Part name: Terminal Block | Remarks: TB-X111(Y002610) | Qty: 1

#6. P/N: KXFP6GE3A00 | Part name: Power Supply | Remarks: ADA600F-24 | Qty: 1

#7. P/N: N510038308AA | Part name: Power Supply | Remarks: PBA15F-24-N | Qty: 1

#8. P/N: KXFP6JTDA00 | Part name: Magnet Contacto | Remarks: SD-Q19 DC24V 1a1b | Qty: 2

#9. P/N: KXFP6GFZA00 | Part name: Magnet Contacto | Remarks: SD-Q12 DC24V 1a1b | Qty: 4

#10. P/N: N510032346AA | Part name: Magnet Switch | Remarks: MSOD-Q11CX(KP) 1.3A 200V DC24V | Qty: 1

#11. P/N: KXFP6GG0A00 | Part name: Surge Killer | Remarks: UN-SA33 | Qty: 1

#12. P/N: N510042706AA | Part name: Circuit Protector | Remarks: CP31FI/15(CCC) | Qty: 1

#13. P/N: N510041592AA | Part name: Circuit Protector | Remarks: CP31FI/10(CCC) | Qty: 5

#14. P/N: N510042705AA | Part name: Circuit Protector | Remarks: CP31FI/5(CCC) | Qty: 2

#15. P/N: N510041642AA | Part name: Circuit Protector Cover | Remarks: CP-T4(UL-94V0) | Qty: 16

#16. P/N: N510025698AA | Part name: Relay | Remarks: G9SC-400-CNP4E | Qty: 1

#17. P/N: N510025759AB | Part name: Relay | Remarks: G9SC-PF | Qty: 1

#18. P/N: KXF077MAA00 | Part name: Fan Guard | Remarks: 109-019E | Qty: 1

#19. P/N: N610074419AA | Part name: Fan | Qty: 1
