KN610159207AA-10-6 NPM Light weight 16 Nozzle Head

#1. P/N: N210188275AA | Part name: Handle | Qty: 2

#2. P/N: N210188276AB | Part name: Post | Qty: 2

#3. P/N: N210188277AB | Part name: Post | Qty: 2

#4. P/N: N210189131AB | Part name: Bracket | Qty: 1

#5. P/N: N210188279AB | Part name: Cover | Qty: 1

#6. P/N: N210188280AC | Part name: Cover | Qty: 1

#7. P/N: N210189158AC | Part name: Bracket | Qty: 1

#8. P/N: N610159301AD | Part name: Bracket | Qty: 1

#9. P/N: N510067530AA | Part name: Joint | Remarks: KQ2U06-01AS | Qty: 2

#10. P/N: N510067913AA | Part name: Joint | Remarks: FR6-01M | Qty: 1

#11. P/N: N510068214AA | Part name: Coupler | Remarks: MA-MS10PF-3LFT(CS38669-0) | Qty: 1

#12. P/N: N510002013AA | Part name: Bolt | Remarks: SRBS-M4X20 | Qty: 2

#13. P/N: N510045431AA | Part name: Screw | Remarks: Cross recessed pan head machine screw with RPW M3X5-4.8 A2S | Qty: 8

#14. P/N: N510001803AA | Part name: Bolt | Remarks: SRBS-M4X12 | Qty: 4

#15. P/N: N510018675AA | Part name: Screw | Remarks: Cross recessed Pan head machine screw with SW & SPW M3X6-4.8 A2J | Qty: 2
