NPM-D3 Feeder Table Cover (Rear Side) N610161828AA

#1. P/N: N210153534AC | Part name: Sheet | Qty: 1

#2. P/N: N210191776AB | Part name: Sheet | Qty: 1

#3. P/N: N210144665AA | Part name: Sheet | Qty: 2

#4. P/N: N210153528AA | Part name: Sheet | Qty: 1

#5. P/N: N210153542AC | Part name: Cover | Qty: 1

#6. P/N: N210166019AA | Part name: Sheet | Qty: 1

#7. P/N: N210166020AA | Part name: Sheet | Qty: 1

#8. P/N: N210153544AD | Part name: Cover | Qty: 1

#9. P/N: N210190676AC | Part name: Bracket | Qty: 1

#10. P/N: N210153548AC | Part name: Cover | Qty: 1

#11. P/N: N210155969AA | Part name: Bracket | Qty: 1

#12. P/N: N210156017AC | Part name: Cover | Qty: 1

#13. P/N: KXFB03UPA00 | Part name: Nut-Plate | Qty: 2

#14. P/N: N210153551AC | Part name: Bracket | Qty: 1

#15. P/N: N210137522AB | Part name: Bracket | Qty: 2

#16. P/N: N210141409AB | Part name: Bracket | Qty: 1

#17. P/N: N210141410AB | Part name: Bracket | Qty: 1

#18. P/N: N210141411AB | Part name: Bracket | Qty: 1

#19. P/N: N210143604AB | Part name: Plate | Qty: 1

#20. P/N: N210143605AD | Part name: Plate | Qty: 1

#21. P/N: N210195666AB | Part name: Plate | Qty: 1

#22. P/N: N210141413AA | Part name: Bracket | Qty: 2

#23. P/N: N210148647AB | Part name: Dog | Qty: 1

#24. P/N: N210143608AC | Part name: Dog | Qty: 1

#25. P/N: N210155962AA | Part name: Plate | Qty: 1

#26. P/N: N210145839AA | Part name: Bracket | Qty: 1

#27. P/N: N210145840AA | Part name: Bracket | Qty: 1

#28. P/N: N210146651AA | Part name: Nut-Plate | Qty: 1

#29. P/N: N510018280AA | Part name: Screw | Remarks: Cross recessed Truss head machine screw M4X6-4.8 A2S (Trivalent) | Qty: 13

#30. P/N: N982TL1072 | Part name: Catch | Remarks: TL-60-1 | Qty: 2

#31. P/N: N510018155AA | Part name: Screw | Remarks: Cross recessed Countersunk head machine screw M3X4-4.8 A2J (Trivalent) | Qty: 4

#32. P/N: N510030564AA | Part name: Spacer | Remarks: CB-409E | Qty: 6

#33. P/N: N510029497AA | Part name: Spacer | Remarks: ASF-445E | Qty: 2

#34. P/N: N510018056AA | Part name: Screw | Remarks: Cross recessed Pan head machine screw M3X6-4.8 A2J (Trivalent) | Qty: 16

#35. P/N: N510043435AA | Part name: Slit | Remarks: OS-EX20-05X3 | Qty: 3

#36. P/N: N510018254AA | Part name: Screw | Remarks: Cross recessed Truss head machine screw M3X6-4.8 A2S (Trivalent) | Qty: 4

#37. P/N: N510018283AA | Part name: Screw | Remarks: Cross recessed Truss head machine screw M4X8-4.8 A2S (Trivalent) | Qty: 5

#38. P/N: N610084447AA | Part name: Sensor | Remarks: (Light Source 500mm,Receiver 1000mm) | Qty: 2

#39. P/N: N610084450AA | Part name: Sensor | Remarks: (Light Source 1000mm,Receiver 500mm) | Qty: 2

#40. P/N: N610162035AA | Part name: Switch(1000Mm) | Qty: 1
