Panasonic NPM 2 Nozzle Head N610157743AA KN610157743AA-10-2

Panasonic Npm 2 Nozzle Head N610157743AA KN610157743AA 10

#1. P/N: N210186137AA | Part name: Plate | Qty: 1

#2. P/N: KXFB0APXA00 | Part name: Joint | Qty: 2

#3. P/N: KXFB0APZA00 | Part name: Joint | Qty: 2

#4. P/N: N210113239AA | Part name: Manifold | Qty: 1

#5. P/N: N210085976AB | Part name: Plate | Qty: 1

#6. P/N: N210085977AD | Part name: Cover | Qty: 1

#7. P/N: N210097158AE | Part name: Bracket | Qty: 1

#8. P/N: N510043456AA | Part name: Motor | Remarks: P50BA2003BCS4D | Qty: 2

#9. P/N: N510020597AA | Part name: Pin | Remarks: MMS4-8 | Qty: 4

#10. P/N: N510043367AA | Part name: Linear Way | Remarks: KR15QZ+0812-0006194(80012465M001) | Qty: 2

#11. P/N: N510067785AA | Part name: Bolt | Remarks: Low Head Cap Screw M3X6-8.8 SOB | Qty: | Qty: | Qty: 16

#12. P/N: N510018280AA | Part name: Screw | Remarks: Cross recessed Truss head machine screw M4X6-4.8 A2S (Trivalent) | Qty: 5

#13. P/N: N510066461AA | Part name: Joint | Remarks: KQ2L06-M5A | Qty: 4

#14. P/N: N510066712AA | Part name: Joint | Remarks: KQ2S06-M5A | Qty: 1

#15. P/N: N510066683AA | Part name: Joint | Remarks: KQ2H08-01AS | Qty: 2

#16. P/N: KXF081WAA00 | Part name: Steel Ball | Remarks: 4.5mm | Qty: 4

#17. P/N: N510015581AA | Part name: Spacer | Remarks: CF-335E | Qty: 2

#18. P/N: N510017331AA | Part name: Bolt | Remarks: Hexagon socket head cap screw M3X45-10.9 A2J (Trivalent) | Qty: 2

#19. P/N: N510034273AA | Part name: Spacer | Remarks: ASF-590E | Qty: 2

#20. P/N: N510019890AA | Part name: Spacer | Remarks: ASF-350E | Qty: 4

#21. P/N: N510031805AA | Part name: Spacer | Remarks: CB-530E | Qty: 2

#22. P/N: N510033408AA | Part name: Washer | Remarks: 87FWSSB-D20.0-V5.0-T3.0 | Qty: 2

#23. P/N: N510066662AA | Part name: Joint | Remarks: KQ2L04-M5A | Qty: 2

#24. P/N: N510017750AA | Part name: Bolt | Remarks: Hexagon head bolt Best class M5X45-6g 4T A2J (Trivalent) | Qty: 2

#25. P/N: N510054501AA | Part name: Valve | Remarks: VQZ115R-5MOZ1-C6-X513 | Qty: 2

#26. P/N: N510054170AA | Part name: Valve | Remarks: VQZ115R-5LOZ1-M5-X550 | Qty: 2

#27. P/N: N510017514AA | Part name: Bolt | Remarks: SSS 003 Hexagon socket button head screw M3X8-10.9 A2J (Trivalent) | Qty: 1

#28. P/N: N510044729AA | Part name: Fan | Remarks: 109L0624H408 | Qty: 1

#29. P/N: N510066732AA | Part name: Joint | Remarks: KQ2Y06-M5A | Qty: 1

#30. P/N: N510066792AA | Part name: Joint | Remarks: KQ2L04-06A | Qty: 1

#31. P/N: N510029639AA | Part name: Steel Ball | Remarks: 6.5mm | Qty: 1

#32. P/N: N610074285AC | Part name: Regulator | Qty: 1
