KN610157741AA-08-4 Panasonic NPM 12 NOZZLE HEAD N610157741AA

KN610157741AA 08 4 Panasonic Npm 12 Nozzle Head N610157741AA

#1. P/N: N210126067AA | Part name: Bracket | Qty: 1

#2. P/N: N210084290AB | Part name: Block | Qty: 2

#3. P/N: N210048480AA | Part name: Pulley | Qty: 2

#4. P/N: N210070043AA | Part name: Block | Qty: 2

#5. P/N: N210084291AB | Part name: Plate | Qty: 2

#6. P/N: N210123391AA | Part name: Coller | Qty: 2

#7. P/N: N210117343AA | Part name: Washer | Qty: 2

#8. P/N: N210118728AA | Part name: Washer | Qty: 2

#9. P/N: N210084292AC | Part name: Guard | Qty: 2

#10. P/N: N210070045AA | Part name: Plate | Qty: 1

#11. P/N: KXF02T0AA00 | Part name: Joint | Remarks: M-5ALU-6|Qty: 4

#12. P/N: KXF05X7AA00 | Part name: Joint | Remarks: M-5E | Qty: 2

#13. P/N: N510031771AA | Part name: Spacer | Remarks: ASU-348 | Qty: 4

#14. P/N: N510067786AA | Part name: Bolt | Remarks: Low Head Cap Screw M3X8-8.8 SOB | Qty: 4

#15. P/N: N510067504AA | Part name: Bearing | Remarks: 693JZZMC3 NS7L | Qty: 4

#16. P/N: XVE25B5FTC | Part name: Bolt | Remarks: Hexagon socket head cap screw M2.5X5-12.9 SOB | Qty: 2

#17. P/N: N510067505AA | Part name: Bearing | Remarks: MR137ZZMC3 NS7L | Qty: 2

#18. P/N: N510032344AA | Part name: Pulley | Remarks: P14-2GT-12-SF(K0610-001-01) | Qty: 2

#19. P/N: N510020589AA | Part name: Pin | Remarks: MMS3-8 | Qty: 4

#20. P/N: N510042809AB | Part name: Motor | Remarks: P50B02002BXS2D | Qty: 2

#21. P/N: N510017322AA | Part name: Bolt | Remarks: Hexagon socket head cap screw M3X25-10.9 A2J (Trivalent) Full thread | Qty: 1

#22. P/N: N510031805AA | Part name: Spacer | Remarks: CB-530E | Qty: 2

#23. P/N: N510017750AA | Part name: Bolt | Remarks: Hexagon head bolt Best class M5X45-6g 4T A2J (Trivalent) | Qty: 2

#24. P/N: N554C03700A | Part name: O-Ring | Remarks: CO3700A | Qty: 12
