KN610157741AA-08-2 Panasonic NPM 12 Nozzle Head N610157741AA

#1. P/N: N210186135AA | Part name: Plate | Qty: 1

#2. P/N: N210078980AB | Part name: Manifold | Qty: 1

#3. P/N: N210090625AB | Part name: Handle | Qty: 2

#4. P/N: N210084658AB | Part name: Bracket | Qty: 1

#5. P/N: N210078994AD | Part name: Bracket | Qty: 1

#6. P/N: N210084293AB | Part name: Plate | Qty: 2

#7. P/N: N210103911AB | Part name: Bracket | Qty: 1

#8. P/N: N510049987AA | Part name: Motor | Remarks: RMTA-A001A12-MA23 | Qty: 1

#9. P/N: N510020607AA | Part name: Pin | Remarks: MMS5-10 | Qty: 4

#10. P/N: N510008161AA | Part name: Spacer | Remarks: ASF-309E | Qty: 2

#11. P/N: N510019890AA | Part name: Spacer | Remarks: ASF-350E | Qty: 4

#12. P/N: N510066777AA | Part name: Joint | Remarks: KQ2H08-02AS | Qty: 2

#13. P/N: KXF02T4AA00 | Part name: Joint | Remarks: M-5AU-6 | Qty: 4

#14. P/N: N510017516AA | Part name: Bolt | Remarks: SSS 003 Hexagon socket button head screw M4X10-10.9 A2J (Trivalent) | Qty: 2

#15. P/N: N510044727AA | Part name: Fan | Remarks: 109P0424H737 | Qty: 1
