HPH (1/3) (Option) on Hanwha (Samsung Techwin) Excellent Modular EXCEN PRO (D) (M) (L)

Hph 1 3 Option On Hanwha Samsung Techwin Excellent Modular Excen Pro D M L

#1. P/N: FC30-001272A | Part name: Plate Center Duct L | Qty: 1

#2. P/N: FC18-001182 | Part name: Spacer Asl 310E | Qty: 2

#3. P/N: FC30-001271A | Part name: Plate Center Duct R | Qty: 1

#4. P/N: FC09-002009A | Part name: Bracket Conector A Spcc Pfznni W | Qty: 2

#5. P/N: FC09-002010A | Part name: Bracket Pipe Guide Spcc Pfznni W | Qty: 1

#6. P/N: FC09-002008A | Part name: Bracket Conector Spcc Pfznni W | Qty: 1

#7. P/N: FC15-001141A | Part name: Cover Main Spcc Pfznni W | Qty: 1

#8. P/N: FC18-000114A | Part name: Stud Support Stud S25 25 Me1 Steel | Qty: 4

#9. P/N: EP06-001012 | Part name: Servo Control Drive D4910V121 | Qty:1 | Old P/N: EP06-000210 / EP06-000472 / EP06-001006

#10. P/N: FC15-001426A | Part name: Cover Front Cover Hp | Qty: 1

#11. P/N: HP13-000009 | Part name: Tube Tube Web8604 (10M) Pl24 Silicon | Qty: 2

#12. P/N: FC38-000061A | Part name: Spring Spring Z Swp B | Qty: 2

#13. P/N: HP13-900032 | Part name: Tube Tu0425W | Qty: 1

#14. P/N: HP13-000019 | Part name: Tube Tube Tu0425B | Qty: 1

#15. P/N: FC18-001187 | Part name: Spacer Asb 336E | Qty: 1

#16. P/N: FC09-002013A | Part name: Bracket Conector C Spcc Pfznni W | Qty: 1

#17. P/N: FC09-002011A | Part name: Bracket Spring Spcc Pfznni W | Qty: 1

#18. P/N: FC18-001182 | Part name: Spacer Asl 310E | Qty: 2

#19. P/N: FC18-001378 | Part name: Bolt Cbsa4 10 Cbsa4 10 M4 10 | Qty: 2

#20. P/N: FC18-000931 | Part name: Spacer Spacer | Qty: 2

#21. P/N: FC09-002012A | Part name: Bracket Spring B Spcc Pfznni W | Qty: 1

#22. P/N: FC18-901046 | Part name: Hex Nut [M4 (Bl/Zn)] | Qty: 2 | Remarks: NUT[M4]
