Cover (3/3) On Hanwha Techwin Excellent Modular EXCEN PRO (D) (M) (L) SMT Component Placer
#1. P/N: FC09-001902A | Part name: Bracket Center L Bkt | Qty: 8
#2. P/N: FC09-001942A | Part name: Bracket T Bkt Outter | Qty: 2
#3. P/N: FC09-001922A | Part name: Bracket Long Elbow Bkt | Qty: 2
#4. P/N: FC18-000311 | Part name: Nut Spring Nut M6 Ykn S306 | Qty: 34
#5. P/N: FC18-000310 | Part name: Nut Spring Nut M4 Ykn S304 | Qty: 12
#6. P/N: FC18-903190 | Part name: Profile Mount Dia 4.0 | Qty: 12
#7. P/N: FC09-000468A | Part name: Bracket Bracket A | Qty: 10
#8. P/N: FC09-001897A | Part name: Bracket Door Sns Bkt A | Qty: 2
#9. P/N: FC09-001893A | Part name: Bracket Gs Bkt A3 | Qty: 4
#10. P/N: FC09-001898A | Part name: Bracket Door Sns Bkt B | Qty: 2
#11. P/N: FC09-001896A | Part name: Bracket Gs Bkt B3 | Qty: 4
#12. P/N: FC39-000867B | Part name: Frame Al Frame X | Qty: 2 | Old P/N: FC39-000867A
#13. P/N: FC09-001919B | Part name: Bracket T Bkt Center | Qty: 2 | Old P/N: FC09-001919A
#14. P/N: FC09-001899A | Part name: Bracket Frame T Bkt | Qty: 4
#15. P/N: FC09-001920A | Part name: Bracket I Bkt Center | Qty: 2
#16. P/N: FC39-000053A | Part name: Frame Al Frame D Me6 Aluminum | Qty: 2
#17. P/N: FC09-001900A | Part name: Bracket Top Cover Bkt 1 | Qty: 4
#18. P/N: FC09-000058A | Part name: Bracket Cn Bkt C Me1 Steel | Qty: 2
#19. P/N: FC39-001253A | Part name: Frame Al Frame C 1447 | Qty: 1 | Old P/N: FC39-000052A
#20. P/N: FC09-000468A | Part name: Bracket Bracket A | Qty: 4
#21. P/N: FC18-903190 | Part name: Profile Mount Dia4.0 | Qty: 12
#22. P/N: FC18-000310 | Part name: Nut Spring Nut M4 Ykn S304 | Qty: 8
#23. P/N: FC18-000311 | Part name: Nut Spring Nut M6 Ykn S306 | Qty: 16
#24. P/N: FC18-900916 | Part name: Nut Square Nut M6 Ykn Sq306 | Qty: 8
#25. P/N: FC39-001253A | Part name: Frame Al Frame C 1447 | Qty: 1
