Cover Tape Winding Section on Hitachi Yamaha SMT Tape Feeder 72mm GT-72001B GD-72001B

#201. P/N: 630 137 4949 | Base

#203. P/N: 630 126 6091 | Assy Gear(Makitori)

#203-01. P/N: 630 126 6022 | Gear(Makitori) 1

#203-02. P/N: 630 126 6039 | Gear(Hira-3) 1

#203-03. P/N: 630 007 1771 | Bearing Radial

#204. P/N: 630 160 2721 | Assy Gear(Hasuba)

#205. P/N: 630 157 1911 | Assy Gear(Hira-1)

#206. P/N: 630 160 1625 | Assy Gear(Hira-2)

#207. P/N: 630 134 0272 | Assy Lever

#208. P/N: 630 134 0302 | Plate

#209. P/N: 630 132 4661 | Pin Hinge(Siten-1)

#210. P/N: 411 141 0000 | Nut Hex

#211. P/N: 630 132 4494 | Cover

#212. P/N: 630 132 4500 | Cover

#213. P/N: 630 127 6601 | Spring Comp

#214. P/N: 630 149 6054 | Lever(Makitori)

#215. P/N: 630 132 4739 | Pin Guide

#216. P/N: 630 132 4746 | Roller(A)

#217. P/N: 630 154 5509 | Roller(B)

#218. P/N: 630 132 4760 | Pin Hinge

#219. P/N: 630 127 5178 | Spring Comp

#220. P/N: 630 126 6602 | Pin Guide(Bane)

#221. P/N: 630 129 0898 | Motor Dc

#222. P/N: 630 110 5390 | Bearing Radial Lf-730Zz

#224. P/N: 630 126 5988 | Pin Locate

#225. P/N: 630 126 6466 | Pin Locate

#227. P/N: 630 132 4777 | Pin Hinge

#228. P/N: 630 000 8494 | Bolt Hex-Sct M2.5X6

#229. P/N: 630 000 7510 | Bolt Hex-Sct M3X8

#230. P/N: 411 125 5403 | Scr Pan 2X4

#231. P/N: 411 000 9304 | Ring E

#232. P/N: 411 016 0203 | Ring E 2.5

#233. P/N: 411 141 6606 | Washer Spr 2.5

#234. P/N: 411 141 2806 | Washer Spr

#235. P/N: 411 141 5708 | Washer F 2.5X5X0.5

#236. P/N: 411 141 3902 | Washer V 3X7X0.5

#237. P/N: 630 000 7565 | Bolt Hex-Sct M3X20

#238. P/N: 630 160 1656 | Assy Gear

#239. P/N: 630 133 5049 | Gear 1

#240. P/N: 630 132 4784 | Pin Hinge

#241. P/N: 630 130 5073 | Plate

#242. P/N: 630 130 5080 | Plate

#243. P/N: 411 142 5004 | Scr Pan 2.5X8

#244. P/N: 630 132 4807 | Bracket

#245. P/N: 630 132 4814 | Bolt

#246. P/N: 411 141 2509 | Washer Spr

#247. P/N: 411 131 5305 | Washer F 2X4.3X0.3

#248. P/N: 630 126 8248 | Set Screw(Set Screw) M2X3 Set

#251. P/N: 411 140 6805 | Scr Flt 2X4

#252. P/N: 630 160 1564 | Collar(Hira-2)

#253. P/N: 630 160 2745 | Collar(Hasuba)

#254. P/N: 411 140 6300 | Scr Pan 2X8

#256. P/N: 630 128 6815 | Cover

#257. P/N: 630 126 1621 | Sensor Photo B03 Ee-Sx3144-P2
