What is JUKI ZEVATECH KE-2010 KE-2020 KE-2030 KE-2040 KE-2050 KE-2060 KE-2070 KE-2080 KE-1070 JX-100 FX-1 Stick Feeder 7.2mm Lane SFN1AS?
Looking for JUKI ZEVATECH KE-2010 KE-2020 KE-2030 KE-2040 KE-2050 KE-2060 KE-2070 KE-2080 KE-1070 JX-100 FX-1 Stick Feeder 7.2mm Lane SFN1AS? This SMT spare part (SKU: SFN1AS, Brand: JUKI) is a high-precision component for SMT pick-and-place machines. Contact SMTBOX for competitive bulk prices, global delivery options, and fast RFQ turnaround.
We offer JUKI ZEVATECH KE-2010 KE-2020 KE-2030 KE-2040 KE-2050 KE-2060 KE-2070 KE-2080 KE-1070 JX-100 FX-1 Stick Feeder 7.2mm Lane SFN1AS. Please contact sales@smtbox.com
Feeder Type | Part No. | Lane (mm) | SOP | QFJ | SOJ | |||
| Width | Height | Width | Height | Width | Height | |||
N0 | SFN0AS | 6.9(*1) | 5.72~8.89 | ~2.0 | – | – | – | – |
| N1 | SFN1AS | 7.2 | 5.72~6.99 | ~1.5 | – | – | – | – |
| N2 | SFN2AS | 9.2 | 7.62~8.89 | 2.0 | 8.05~8.51 | 4.20~4.57 | 8.38~8.76 | 3.25~3.76 |
| N3 | SFN3AS | 11.2 | 9.53~10.8 | 2.5 | 9.78~10.03 | 4.20~4.57 | 9.65~10.03 | 3.25~3.76 |
| N4 | SFN4AS | 13.0 | 11.43~12.7 | 3.0 | 12.32~12.57 | 4.20~4.57 | 10.92~12.57 | 3.25~3.76 |
| W1 | SFW1AS | 15.0 | 13.34~14.61 | 3.5 | – | – | – | – |
| W2 | SFW2AS | 18.2 | 15.24~16.51 | 4.0 | 17.40~17.65 | 4.20~4.57 | – | – |
| W3 | SFW3AS | 20.8 | – | – | 19.94~20.19 | 4.20~4.57 | – | – |
| W4 | SFW4AS | 26.0 | – | – | 25.02~25.27 | 4.20~4.57 | – | – |
| W5 | SFW5AS | 31.2 | – | – | 30.10~30.55 | 4.20~4.57 | – | – |
| Stick Feeder Spacer Kit | |||||||||||
| Spacer Kit | Thickness | N0 | N1 | N2 | N3 | N4 | W1 | W2 | W3 | W4 | W5 |
| Spacer A | 0.5mm | 2 | – | – | – | – | – | – | – | – | – |
| Spacer B | 1.0mm | – | – | 2 | – | – | – | – | – | – | – |
| Spacer C | 1.6mm | – | – | – | – | – | – | 2 | – | – | – |
| Spacer D | 2.0mm | – | – | – | 2 | – | – | – | – | – | – |
| Spacer E | 2.6mm | – | – | – | – | – | – | – | – | 2 | 4 |
| Spacer F | 2.9mm | – | – | – | – | 2 | – | – | 2 | 2 | 2 |
| Spacer G | 0.3mm | 4 | – | – | – | – | – | – | – | – | – |
The JUKI ZEVATECH KE-2010 KE-2020 KE-2030 KE-2040 KE-2050 KE-2060 KE-2070 KE-2080 KE-1070 JX-100 FX-1 Stick Feeder 7.2mm Lane SFN1AS (SKU: SFN1AS) is a premium-grade SMT spare component manufactured for high-speed pick and place machines. Designed for maximum durability and precision, this part is part of our extensive JUKI SMT Feeders, JUKI SMT Spare Parts, SMD Stick Feeders , SMT Feeders Sort by Type inventory. It ensures seamless integration and high efficiency on active PCB assembly lines.
How to use JUKI ZEVATECH KE-2010 KE-2020 KE-2030 KE-2040 KE-2050 KE-2060 KE-2070 KE-2080 KE-1070 JX-100 FX-1 Stick Feeder 7.2mm Lane SFN1AS?
For optimal performance and durability, this component should be installed and calibrated by a certified SMT maintenance engineer. Regularly check the alignment, wear patterns, and vacuum suction parameters (for nozzles) to prevent component mispicks and ensure high assembly yields.
- Power down your mounter and disconnect the vacuum line.
- Clean the nozzle shaft or feeder mounting slot with ESD-safe cleaning alcohol.
- Carefully align the new component and tighten to the manufacturer's torque specifications.
- Perform a test cycle and verify the component alignment using mounter diagnostics before resuming full production.
