P-3 Cover Tape Winding Section of Hitachi Yamaha SMT Tape Feeder GT-24321B GD-24321B

#201 P/N: 630 137 4949 | Base

#203 P/N: 630 126 6091 | Assy Gear(Makitori)

#204 P/N: 630 160 2721 | Assy Gear(Hasuba)

#206 P/N: 630 160 1526 | Assy Gear(Hira-2)

#207 P/N: 630 157 4387 | Assy Lever

#207-01 P/N: 630 157 1690 | Lever 1

#207-02 P/N: 630 157 4356 | Assy Gear(Hira-1) 1

#207-03 P/N: 630 127 9558 | Pin Hinge 1

#207-04 P/N: 630 157 1676 | Cover 1

#207-05 P/N: 411 000 9304 | Ring E

#207-06 P/N: 411 125 5403 | Scr Pan 2X4 2

#207-07 P/N: 411 141 2509 | Washer Spr

#207-08 P/N: 411 131 5305 | Washer F 2X4.3X0.3 2

#207-09 P/N: 411 140 6805 | Scr Flt 2X4 2

#209 P/N: 630 127 9404 | Pin Hinge

#210 P/N: 411 141 0000 | Nut Hex

#212 P/N: 630 127 9107 | Cover(Makitori-2)

#213 P/N: 630 127 6601 | Spring Comp

#214 P/N: 630 149 6030 | Lever(Makitori)

#215 P/N: 630 127 9442 | Pin Guide

#216 P/N: 630 127 9466 | Roller(A)

#217 P/N: 630 154 4243 | Roller(B)

#218 P/N: 630 127 9480 | Pin Hinge

#219 P/N: 630 127 5178 | Spring Comp

#220 P/N: 630 126 6602 | Pin Guide(Bane)

#221 P/N: 630 129 0898 | Motor Dc

#222 P/N: 630 110 5390 | Bearing Radial Lf-730Zz

#224 P/N: 630 126 5988 | Pin Locate

#225 P/N: 630 126 6466 | Pin Locate

#227 P/N: 630 127 9503 | Pin Hinge

#228 P/N: 630 000 8494 | Bolt Hex-Sct M2.5X6

#229 P/N: 630 000 7510 | Bolt Hex-Sct M3X8

#230 P/N: 411 125 5403 | Scr Pan 2X4

#231 P/N: 411 000 9304 | Ring E

#232 P/N: 411 016 0203 | Ring E 2.5

#233 P/N: 411 141 6606 | Washer Spr 2.5

#234 P/N: 411 141 2806 | Washer Spr

#235 P/N: 411 141 5708 | Washer F 2.5X5X0.5

#236 P/N: 411 141 3902 | Washer V 3X7X0.5

#237 P/N: 630 000 7503 | Bolt Hex-Sct M3X6

#238 P/N: 630 160 1557 | Gear

#239 P/N: 630 133 5049 | Gear

#241 P/N: 630 127 9565 | Plate

#242 P/N: 630 127 9572 | Plate

#243 P/N: 411 142 5004 | Scr Pan 2.5X8

#246 P/N: 411 141 2509 | Washer Spr

#247 P/N: 411 131 5305 | Washer F 2X4.3X0.3

#248 P/N: 630 126 8248 | Set Screw(Set Screw) M2X3 Set

#251 P/N: 630 128 6815 | Cover

#252 P/N: 630 160 1564 | Collar(Hira-2)

#253 P/N: 630 160 2745 | Collar(Hasuba)

#254 P/N: 411 140 6300 | Scr Pan 2X8

#257 P/N: 630 126 1621 | Sensor Photo Ee-Sx3144-P2
