Flux (5/5) on Hanwha (Samsung Techwin) Excellent Modular EXCEN PRO (D) (M) (L)

#1. P/N: FC29-001464A | Part name: Dog Disk Dog | Qty: 1

#2. P/N: EP08-900083 | Part name: Motor Sh1421 5212 | Qty: 1

#3. P/N: FC30-001068A | Part name: Plate S Motor Plt | Qty: 1

#4. P/N: MC03-900118 | Part name: Bearing 6901Zz | Qty: 2

#5. P/N: FC39-000948A | Part name: Frame Top Frame | Qty: 1

#6. P/N: MC11-900060 | Part name: Cam Follower Cf5Fbuur | Qty: 1

#7. P/N: FC30-001074A | Part name: Plate Cam F Bar | Qty: 1

#8. P/N: J70691502A | Part name: Cam Flux J70691502A | Qty: 1

#9. P/N: FC29-001458A | Part name: Holder Brg Holder S | Qty: 1

#10. P/N: MC13-900124 | Part name: Lm Guide Lwlc9C2R60Bh | Qty: 4

#11. P/N: FC30-001076A | Part name: Plate Lm Plate | Qty: 1

#12. P/N: FC09-002097A | Part name: Bracket Sensor Bracket | Qty: 1

#13. P/N: EP19-900154 | Part name: Sensor EE-Sx972 C1 Ee Sx972 C1 | Qty: 1

#14. P/N: J70653549A | Part name: Bottom Loc Pin J70653549A | Qty: 1

#15. P/N: FC38-000090 | Part name: Spring Etc Awu8 40 Swp A Awu8 40 | Qty: 2

#16. P/N: FC29-001469A | Part name: Post Spg Post A | Qty: 2

#17. P/N: EP08-900082 | Part name: Motor 103H7121 0740 | Qty: 1

#18. P/N: FC14-900273 | Part name: Coupling Xbs 19C2 6 Bt 6.35 Bt | Qty: 1

#19. P/N: FC30-001067A | Part name: Plate T Motor Plt | Qty: 1

#20. P/N: FC18-900915 | Part name: Bearing Nut Bnrc8 | Qty: 1

#21. P/N: FC29-001465A | Part name: Collar Brg Collar | Qty: 1

#22. P/N: MC03-900080 | Part name: Ball Bearing 608Zz | Qty: 2

#23. P/N: FC29-001455A | Part name: Holder Brg Holder T | Qty: 1

#24. P/N: J70691542A | Part name: Plate R J70691542A | Qty: 1

#25. P/N: FC29-001457A | Part name: Post Rib | Qty: 1

#26. P/N: FC29-001461A | Part name: Holder Roller Holder | Qty: 1

#27. P/N: J70653553A | Part name: Clamping Roller | Qty: 1

#28. P/N: J70653554A | Part name: Clamp Block Shaft | Qty: 1

#29. P/N: FC39-000947A | Part name: Frame Side Frame | Qty: 1

#30. P/N: FC39-000946A | Part name: Frame Bottom Frame | Qty: 1
