The information presented in this page applies to the following MVME162P4 models:
#1 Model Number: MVME162P-244L | Characteristics: 25MHz 68LC040, 16MB SDRAM, 2 SIO, 4 DMA IP
#2 Model Number: MVME162P-244LE | Characteristics: 25MHz 68LC040, 16MB SDRAM, 2 SIO, 4 DMA IP, Ethernet
#3 Model Number: MVME162P-244LSE | Characteristics: 25MHz 68LC040, 16MB SDRAM, 2 SIO, 4 DMA IP, SCSI/Ethernet
#4 Model Number: MVME162P-344 | Characteristics: 32MHz 68040, 16MB SDRAM, 2 SIO, 4 DMA IP
#5 Model Number: MVME162P-344S | Characteristics: 32MHz 68040, 16MB SDRAM, 2 SIO, 4 DMA IP, SCSI
#6 Model Number: MVME162P-344E | Characteristics: 32MHz 68040, 16MB SDRAM, 2 SIO, 4 DMA IP, Ethernet
#7 Model Number: MVME162P-344SE | Characteristics: 32MHz 68040, 16MB SDRAM, 2 SIO, 4 DMA IP, SCSI/Ethernet
Note: Model Number: MVME162P-344SE, Characteristics: 32MHz 68040, 16MB SDRAM, 2 SIO, 4 DMA IP, SCSI/Ethernet is used on Universal UIC HSP4797L Hitachi Sanyo TCM-X100 P.C.B. Mount Part number：6300901030 6300859393.
