TDK AI Replacement Spare Parts for Auto-Insert Through Hole Thru-hole Machine 562-F-4420 GEAR – 562-H-3340 PISTON ROD
| No. | Part No. | Part Name |
|---|---|---|
| 751 | 562-F-4420 | GEAR |
| 752 | 562-G-0010 | SPRING PAWL |
| 753 | 562-G-0060 | CHUCK PROPER |
| 754 | 562-G-0070 | CHUCK PAWL-R |
| 755 | 562-G-0080 | CHUCK PAWL-L |
| 756 | 562-G-0090 | HOLDER |
| 757 | 562-G-0102 | COMPRESSION SPRING |
| 758 | 562-G-1010 | HOLDER |
| 759 | 562-G-2010 | SLIDER |
| 760 | 562-G-2020 | CHUCK PROPER |
| 761 | 562-G-8000 | CHUCK HALF UNIT |
| 762 | 562-G-8010 | CHUCK UNIT |
| 763 | 562-H-0010 | PIN |
| 764 | 562-H-0020 | ROLLER |
| 765 | 562-H-0030 | LEVER |
| 766 | 562-H-0041 | PIN RETAINER |
| 767 | 562-H-0070 | ROLLER |
| 768 | 562-H-0080 | SHAFT |
| 769 | 562-H-0102 | SLIDER |
| 770 | 562-H-0120 | PIN |
| 771 | 562-H-0150 | JOINT PIN |
| 772 | 562-H-0170 | PIN HOLDER |
| 773 | 562-H-0200 | CLAMP SHAFT |
| 774 | 562-H-0200S | CLAMP SHAFT |
| 775 | 562-H-0220 | RACK GUIDE |
| 776 | 562-H-0230 | CYLINDER BRACKET |
| 777 | 562-H-0250 | STOPPER |
| 778 | 562-H-0310 | SLIDE |
| 779 | 562-H-0320 | TENSION SPRING |
| 780 | 562-H-0350 | PUSH ROD-PIECE |
| 781 | 562-H-0351 | PUSH ROD-PIECE |
| 782 | 562-H-0370 | COMPRESSION SPRING |
| 783 | 562-H-1370 | PUSH ROD PIECE |
| 784 | 562-H-1380 | BOLT 562-H-3080 |
| 785 | 562-H-1390 | SPRING |
| 786 | 562-H-1400 | CLAMP SHAFT |
| 787 | 562-H-1401 | CLAMP SHAFT |
| 788 | 562-H-1410 | SLIDE |
| 789 | 562-H-1420 | LINK HOLDER |
| 790 | 562-H-1430 | CUSHION PIN |
| 791 | 562-H-3070 | CONNECTING ROD |
| 792 | 562-H-3080 | HEXAGON HEAD BOLT |
| 793 | 562-H-3110 | ROD END |
| 794 | 562-H-3120 | ROD END |
| 795 | 562-H-3130 | PIN |
| 796 | 562-H-3260 | CHUCK OPEN LEVER |
| 797 | 562-H-3270 | CHUCK OPEN KEY |
| 798 | 562-H-3301 | SLIDE |
| 799 | 562-H-3301J | SLIDE |
| 800 | 562-H-3340 | PISTON ROD |
